7. IP Core Interfaces
This chapter describes the signals that are part of the Cyclone V Hard IP for PCI
Express IP core. It describes the top-level signals in the following IP cores:
■ Cyclone V Hard IP for PCI Express
■ Avalon-MM Hard IP for PCI Express
Variants using the Avalon-ST interface are available in both the MegaWizard Plug-In
Manager and the Qsys design flows. Variants using the Avalon-MM interface are only
available in the Qsys design flow. Variants using the Avalon-ST interfaces offer a
richer feature set; however, if you are not familiar with the PCI Express protocol,
variants using the Avalon-MM interface may be easier to understand. The
Avalon-MM variants include a PCI Express to Avalon-MM bridge that translates the
PCI Express read, write and completion Transaction Layer Packets (TLPs) into
standard Avalon-MM read and write commands typically used by master and slave
interfaces to access memories and registers. Consequently, you do not need a detailed
understanding of the PCI Express TLPs to use the Avalon-MM variants. Refer to
“Differences in Features Available Using the Avalon-MM and Avalon-ST Interfaces”
on page 1–2 to learn about the difference in the features available for the Avalon-ST
and Avalon-MM interfaces.
Because the Cyclone V Hard IP for PCI Express offers exactly the same feature set in
the MegaWizard Plug-In Manager and Qsys design flows, your decision about which
design flow to use depends on whether you want to integrate the Cyclone V Hard IP
for PCI Express using RTL instantiation or Qsys. The Qsys system integration tool
automatically generates the interconnect logic between the IP components in your
system, saving time and effort. Refer to “MegaWizard Plug-In Manager Design Flow”
on page 2–3 and “Qsys Design Flow” on page 2–10 for a description of the steps
involved in the two design flows.
Table 7–1 lists each interface and provides a link to the subsequent sections that
describe each signal. The signals are described in the order in which they are shown in
Figure 7–3.
Table 7–1. Signal Groups in the Cyclone V Hard IP for PCI Express (Part 1 of 2)
Signal Group Description
Logical
Avalon-ST RX “Avalon-ST RX Interface” on page 7–6
Avalon-ST TX “Avalon-ST TX Interface” on page 7–16
Clock “Clock Signals” on page 7–24
Reset and link training “Reset Signals” on page 7–25
ECC error “ECC Error Signals” on page 7–28
Interrupt “Interrupts for Endpoints” on page 7–28
Interrupt and global error “Interrupts for Root Ports” on page 7–28
Configuration space “Transaction Layer Configuration Space Signals” on page 7–31
LMI “LMI Signals” on page 7–39
