Chapter 5: Parameter Settings for the Avalon-MM Cyclone V Hard IP for PCI Express 5–9
Avalon Memory-Mapped System Settings
December 2013 Altera Corporation Cyclone V Hard IP for PCI Express
User Guide
Avalon Memory-Mapped System Settings
Table 5–10 lists the Avalon-MM system parameter registers.
Table 5–10. Avalon Memory-Mapped System Settings
Parameter Value Description
Avalon-MM data
width
64-bit
128-bit
Specifies the interface width between the PCI Express Transaction Layer
and the Application Layer. Refer to Table 9–2 on page 9–6 for a
comprehensive list of available link width, interface width, and frequency
combinations.
Peripheral Mode
Requester/Completer,
Completer-Only
Specifies whether the Avalon-MM Cyclone V Hard IP for PCI Express is
capable of sending requests to the upstream PCI Express devices.
Requester/Completer—In this mode, the Hard IP can send request
packets on the PCI Express TX link and receive request packets on the
PCI Express RX link.
Completer-Only—In this mode, the Hard IP can receive requests, but
cannot initiate upstream requests. However, it can transmit completion
packets on the PCI Express TX link. This mode removes the Avalon-MM
TX slave port and thereby reduces logic utilization.
Single DW completer On/Off
This is a non-pipelined version of Completer-Only mode. At any time, only
a single request can be outstanding. Single dword completer uses fewer
resources than Completer-Only. This variant is targeted for systems that
require simple read and write register accesses from a host CPU. If you
select this option, the width of the data for RXM BAR masters is always 32
bits, regardless of the Avalon-MM width.
Control Register
Access (CRA)
Avalon-MM slave
port
On/Off
Allows read and write access to bridge registers from the interconnect
fabric using a specialized slave port. This option is required for
Requester/Completer variants and optional for Completer-Only variants.
Enabling this option allows read and write access to bridge registers. This
option is not available for the Single dword completer.
Enable multiple
MSI/MSI-X support
On/Off
When you turn this option On, the core includes top-level MSI and MSI-X
interfaces that you can use to implement a Customer Interrupt Handler for
MSI and MSI-X interrupts. For more information about the Custom
Interrupt Handler, refer to Interrupts for End Points Using the Avalon-MM
Interface with Multiple MSI/MSI-X Support.
Auto Enable PCIe
interrupt (enabled at
power-on)
On/Off
Turning on this option enables the Avalon-MM Cyclone V Hard IP for PCI
Express interrupt register at power-up. Turning off this option disables the
interrupt register at power-up. The setting does not affect run-time
configuration of the interrupt enable register.
