Chapter 5: Parameter Settings for the Avalon-MM Cyclone V Hard IP for PCI Express 5–7
PCI Express/PCI Capabilities
December 2013 Altera Corporation Cyclone V Hard IP for PCI Express
User Guide
MSI-X
Table 5–7 describes the MSI-X Capabilities register parameters.
Table 5–8. MSI and MSI-X Capabilities 0x068–0x06C
Parameter Value Description
Implement MSI-X On/Off When On, enables the MSI-X functionality.
Bit Range
Table size
0x068[26:16]
[10:0]
System software reads this field to determine the MSI-X Table size <n>, which is
encoded as <n–1>. For example, a returned value of 2047 indicates a table size of
2048. This field is read-only. Legal range is 0–2047 (2
11
).
Table Offset [31:0]
Points to the base of the MSI-X Table. The lower 3 bits of the table BAR indicator
(BIR) are set to zero by software to form a 32-bit qword-aligned offset. This field is
read-only. Legal range is 0–2
28
.
Table BAR Indicator [2:0]
Specifies which one of a function’s BARs, located beginning at 0x10 in
Configuration Space, is used to map the MSI-X table into memory space. This field
is read-only. Legal range is 0–5.
Pending Bit Array
(PBA) Offset
[31:0]
Used as an offset from the address contained in one of the function’s Base
Address registers to point to the base of the MSI-X PBA. The lower 3 bits of the
PBA BIR are set to zero by software to form a 32-bit qword-aligned offset. This
field is read-only. Legal range is 0–2
28
.
PBA BAR Indicator
(BIR)
[2:0]
Indicates which of a function’s Base Address registers, located beginning at 0x10
in Configuration Space, is used to map the function’s MSI-X PBA into memory
space. This field is read-only. Legal range is 0–5.
