4–10 Chapter 4: Parameter Settings for the Cyclone V Hard IP for PCI Express
Port Functions
Cyclone V Hard IP for PCI Express December 2013 Altera Corporation
User Guide
Link
Table 4–12 describes the Link Capabilities register parameters.
MSI
Table 4–12 describes the MSI Capabilities register parameters.
Table 4–11. Link 0x090
Parameter Value Description
Data link layer active
reporting
On/Off
Turn On this parameter for a downstream port, if the component supports the
optional capability of reporting the DL_Active state of the Data Link Control and
Management State Machine. For a hot-plug capable downstream port (as
indicated by the
Hot-Plug Capable
field of the
Slot
Capabilities
register),
this parameter must be turned On. For upstream ports and components that do
not support this optional capability, turn Off this option. This parameter is only
supported in Root Port mode.
Surprise down
reporting
On/Off
When this option is On, a downstream port supports the optional capability of
detecting and reporting the surprise down error condition. This parameter is only
supported in Root Port mode.
Table 4–12. MSI and MSI-X Capabilities –0x05C,
Parameter Value Description
MSI messages
requested
1, 2, 4,
8, 16
Specifies the number of messages the Application Layer can request. Sets the
value of the
Multiple Message Capable
field of the
Message Control
register, 0x050[31:16].
