3–10 Chapter 3: Getting Started with the Avalon-MM Cyclone Hard IP for PCI Express
Specifying Address Assignments
Cyclone V Hard IP for PCI Express December 2013 Altera Corporation
User Guide
Specifying Address Assignments
Qsys requires that you resolve the base addresses of all Avalon-MM slave interfaces in
the Qsys system. You can either use the auto-assign feature, or specify the base
addresses manually. To use the auto-assign feature, on the System menu, click Assign
Base Addresses. In the design example, you assign the base addresses manually.
The Avalon-MM Cyclone Hard IP for PCI Express assigns base addresses to each
BAR. The maximum supported BAR size is 4 GByte, or 32 bits.
Follow these steps to assign a base address to an Avalon-MM slave interface
manually:
1. In the row for the Avalon-MM slave interface base address you want to specify,
click the Base column.
2. Type your preferred base address for the interface.
3. Assign the base addresses listed in Table 3–13.
The following figure illustrates the complete system.
For this example BAR1:0 is 22 bits or 4 MBytes. This BAR accesses Avalon addresses
from 0x00200000– 0x00200FFF. BAR2 is 15 bits or 32 KBytes. BAR2 accesses the DMA
control_port_slave at offsets 0x00004000 through 0x0000403F. The pci_express
CRA
slave port is accessible at offsets 0x0000000–0x0003FFF from the programmed BAR2
base address. For more information on optimizing BAR sizes, refer to “Minimizing
BAR Sizes and the PCIe Address Space” on page 7–21.
Simulating the Example Design
Follow these steps to generate the files for the testbench and synthesis.
1. On the Generation tab, in the Simulation section, set the following options:
a. For Create simulation model, select None. (This option allows you to create a
simulation model for inclusion in your own custom testbench.)
b. For Create testbench Qsys system, select Standard, BFMs for standard
Avalon interfaces.
c. For Create testbench simulation model, select Ve ri lo g.
2. In the Synthesis section, turn on Create HDL design files for synthesis.
3. Click the Generate button at the bottom of the tab.
Table 3–13. Base Address Assignments for Avalon-MM Slave Interfaces
Interface Name Exported Name
DUT
Txs 0x00000000
DUT
Cra 0x00000000
DMA
control_port_slave 0x00004000
onchip_memory_0
s1 0x00200000
