Chapter 17: Testbench and Design Example 17–47
BFM Procedures and Functions
December 2013 Altera Corporation Cyclone V Hard IP for PCI Express
User Guide
msi_poll Procedure
The
msi_poll
procedure tracks MSI completion from the Endpoint.
dma_set_msi Procedure
The
dma_set_msi
procedure sets PCI Express native MSI for the DMA read or the
DMA write.
Table 17–62. msi_poll Procedure
Location altpcietb_bfm_driver_rp.v
Syntax
msi_poll(max_number_of_msi,msi_address,msi_expected_dmawr,msi_expected_dmard,dma_wri
te,dma_read)
Arguments
max_number_of_msi
Specifies the number of MSI interrupts to wait for.
msi_address
The shared memory location to which the MSI messages will be written.
msi_expected_dmawr
When
dma_write
is set, this specifies the expected MSI data value for the
write DMA interrupts which is set by the
dma_set_msi
procedure.
msi_expected_dmard
When the
dma_read
is set, this specifies the expected MSI data value for the
read DMA interrupts which is set by the
dma_set_msi
procedure.
Dma_write
When set, poll for MSI from the DMA write module.
Dma_read
When set, poll for MSI from the DMA read module.
Table 17–63. dma_set_msi Procedure
Location altpcietb_bfm_driver_rp.v
Syntax
dma_set_msi(bar_table, bar_num, bus_num, dev_num, fun_num, direction, msi_address,
msi_data, msi_number, msi_traffic_class, multi_message_enable, msi_expected)
Arguments
bar_table
Address of the Endpoint
bar_table
structure in BFM shared memory.
bar_num
BAR number to analyze.
Bus_num
Set configuration bus number.
dev_num
Set configuration device number.
Fun_num
Set configuration function number.
Direction
When 0 the direction is read.
When 1 the direction is write.
msi_address
Specifies the location in shared memory where the MSI message data
will be stored.
msi_data
The 16-bit message data that will be stored when an MSI message is
sent. The lower bits of the message data will be modified with the
message number as per the PCI specifications.
Msi_number
Returns the MSI number to be used for these interrupts.
Msi_traffic_class
Returns the MSI traffic class value.
Multi_message_enable
Returns the MSI multi message enable status.
msi_expected
Returns the expected MSI data value, which is
msi_data
modified by the
msi_number
chosen.
