Chapter 17: Testbench and Design Example 17–43
BFM Procedures and Functions
December 2013 Altera Corporation Cyclone V Hard IP for PCI Express
User Guide
dimage3
This function creates a three-digit decimal string representation of the input argument
that can be concatenated into a larger message string and passed to
ebfm_display
.
dimage4
This function creates a four-digit decimal string representation of the input argument
that can be concatenated into a larger message string and passed to
ebfm_display
.
dimage5
This function creates a five-digit decimal string representation of the input argument
that can be concatenated into a larger message string and passed to
ebfm_display.
dimage6
This function creates a six-digit decimal string representation of the input argument
that can be concatenated into a larger message string and passed to
ebfm_display
.
Table 17–50. dimage3
Location altpcietb_bfm_driver_rp.v
syntax
string:= dimage(vec)
Argument range
vec
Input data type
reg
with a
range
of 31:0.
Return range string
Returns a 3-digit decimal representation of the input argument that is padded with leading
0s if necessary. Return data is type
reg
with a
range
of 24:1.
Returns the letter U if the value cannot be represented.
Table 17–51. dimage4
Location altpcietb_bfm_driver_rp.v
syntax
string:= dimage(vec)
Argument range
vec
Input data type
reg
with a
range
of 31:0.
Return range
string
Returns a 4-digit decimal representation of the input argument that is padded with
leading 0s if necessary. Return data is type
reg
with a
range
of 32:1.
Returns the letter U if the value cannot be represented.
Table 17–52. dimage5
Location altpcietb_bfm_driver_rp.v
syntax
string:= dimage(vec)
Argument range
vec
Input data type
reg
with a
range
of 31:0.
Return range
string
Returns a 5-digit decimal representation of the input argument that is padded with leading
0s if necessary. Return data is type
reg
with a
range
of 40:1.
Returns the letter U if the value cannot be represented.
Table 17–53. dimage6
Location altpcietb_bfm_log.v
syntax
string:= dimage(vec)
