17–38 Chapter 17: Testbench and Design Example
BFM Procedures and Functions
Cyclone V Hard IP for PCI Express December 2013 Altera Corporation
User Guide
You can suppress the display of certain message types. The default values
determining whether a message type is displayed are defined in Table 17–36. To
change the default message display, modify the display default value with a
procedure call to
ebfm_log_set_suppressed_msg_mask
.
Certain message types also stop simulation after the message is displayed.
Table 17–36 shows the default value determining whether a message type stops
simulation. You can specify whether simulation stops for particular messages with the
procedure
ebfm_log_set_stop_on_msg_mask
.
All of these log message constants type
integer
.
Table 17–36. Log Messages
Constant (Message Type) Description
Mask
Bit No
Display
by Default
Simulation
Stops by
Default
Message
Prefix
EBFM_MSG_DEBUG
Specifies debug messages. 0 No No
DEBUG:
EBFM_MSG_INFO
Specifies informational messages,
such as configuration register
values, starting and ending of
tests.
1Yes No
INFO:
EBFM_MSG_WARNING
Specifies warning messages, such
as tests being skipped due to the
specific configuration.
2Yes No
WARNING:
EBFM_MSG_ERROR_INFO
Specifies additional information for
an error. Use this message to
display preliminary information
before an error message that stops
simulation.
3Yes No
ERROR:
EBFM_MSG_ERROR_CONTINUE
Specifies a recoverable error that
allows simulation to continue. Use
this error for data miscompares.
4Yes No
ERROR:
EBFM_MSG_ERROR_FATAL
Specifies an error that stops
simulation because the error leaves
the testbench in a state where
further simulation is not possible.
N/A
Yes
Cannot
suppress
Yes
Cannot
suppress
FATAL:
EBFM_MSG_ERROR_FATAL_TB_ERR
Used for BFM test driver or Root
Port BFM fatal errors. Specifies an
error that stops simulation because
the error leaves the testbench in a
state where further simulation is
not possible. Use this error
message for errors that occur due
to a problem in the BFM test driver
module or the Root Port BFM, that
are not caused by the Endpoint
Application Layer being tested.
N/A
Y
Cannot
suppress
Y
Cannot
suppress
FATAL:
