17–30 Chapter 17: Testbench and Design Example
BFM Procedures and Functions
Cyclone V Hard IP for PCI Express December 2013 Altera Corporation
User Guide
ebfm_barrd_wait Procedure
The
ebfm_barrd_wait
procedure reads a block of data from the offset of the specified
Endpoint BAR and stores it in BFM shared memory. The length can be longer than the
configured maximum read request size; the procedure breaks the request up into
multiple transactions as needed. This procedure waits until all of the completion data
is returned and places it in shared memory.
ebfm_barrd_nowt Procedure
The
ebfm_barrd_nowt
procedure reads a block of data from the offset of the specified
Endpoint BAR and stores the data in BFM shared memory. The length can be longer
than the configured maximum read request size; the procedure breaks the request up
into multiple transactions as needed. This routine returns as soon as the last read
transaction has been accepted by the VC interface module, allowing subsequent reads
to be issued immediately.
Table 17–22. ebfm_barrd_wait Procedure
Location altpcietb_bfm_driver_rp.v
Syntax
ebfm_barrd_wait(bar_table, bar_num, pcie_offset, lcladdr, byte_len, tclass)
Arguments
bar_table
Address of the Endpoint
bar_table
structure in BFM shared memory. The
bar_table structure stores the address assigned to each BAR so that the driver code
does not need to be aware of the actual assigned addresses only the Application
Layer specific offsets from the BAR.
bar_num
Number of the BAR used with
pcie_offset
to determine PCI Express address.
pcie_offset
Address offset from the BAR base.
lcladdr
BFM shared memory address where the read data is stored.
byte_len
Length, in bytes, of the data to be read. Can be 1 to the minimum of the bytes
remaining in the BAR space or BFM shared memory.
tclass
Traffic class used for the PCI Express transaction.
Table 17–23. ebfm_barrd_nowt Procedure
Location altpcietb_bfm_driver_rp.v
Syntax
ebfm_barrd_nowt(bar_table, bar_num, pcie_offset, lcladdr, byte_len, tclass)
Arguments
bar_table
Address of the Endpoint
bar_table
structure in BFM shared memory.
bar_num
Number of the BAR used with
pcie_offset
to determine PCI Express address.
pcie_offset
Address offset from the BAR base.
lcladdr
BFM shared memory address where the read data is stored.
byte_len
Length, in bytes, of the data to be read. Can be 1 to the minimum of the bytes
remaining in the BAR space or BFM shared memory.
tclass
Traffic Class to be used for the PCI Express transaction.
