Chapter 17: Testbench and Design Example 17–25
Root Port BFM
December 2013 Altera Corporation Cyclone V Hard IP for PCI Express
User Guide
Besides the
ebfm_cfg_rp_ep
procedure inaltpcietb_bfm_driver_rp.v, routines to read
and write Endpoint Configuration Space registers directly are available in the Verilog
HDL include file. After the
ebfm_cfg_rp_ep
procedure is run the PCI Express I/O and
Memory Spaces have the layout as described in the following three figures. The
memory space layout is dependent on the value of the addr_map_4GB_limit input
parameter. If addr_map_4GB_limit is 1 the resulting memory space map is shown in
Figure 17–5.
Figure 17–5. Memory Space Layout—4 GByte Limit
Root Complex Shared
Memory
0x0000 0000
Configuration Scratch
Space
Used by BFM routines,
not writable by user calls
or endpoint
0x001F FF80
BAR Table
Used by BFM routines ,
not writable by user calls
or endpoint
0x001F FFC0
Endpoint Non-
Prefetchable Memory
Space BARs
Assigned Smallest to
Largest
0x0020 0000
0xFFFF FFFF
Endpoint Memory Space
BARs
(Prefetchable 32 -bit and
64- bit)
Assigned Smallest to
Largest
Unused
Addr
