9. Reset and Clocks
This chapter covers the functional aspects of the reset and clock circuitry for the
Cyclone V Hard IP for PCI Express. It includes the following sections:
■ Reset
■ Clocks
For descriptions of the available reset and clock signals refer to “Reset Signals” on
page 7–24 and “Clock Signals” on page 7–23.
Reset
Hard IP for PCI Express includes two types of embedded reset controllers. One reset
controller is implemented in soft logic. A second reset controller is implemented in
hard logic. Software selects the appropriate reset controller depending on the
configuration you specify. Both reset controllers reset the Hard IP for PCI Express IP
Core and provide sample reset logic in the example design. Figure 9–1 on page 9–2
provides a simplified view of the logic that implements both reset controllers.
Table 9–1 summarizes their functionality.
1 Contact Altera if you are designing with a Gen1 variant and want to use the soft reset
controller.
Table 9–1. Use of Hard and Soft Reset Controllers
Reset Controller Used Description
Hard Reset Controller
pin_perstn
from the input pin of the FPGA resets the Hard IP for PCI
Express IP Core.
npor
is asserted if either
pin_perstn
or
local_rstn
is asserted. Application Layer logic generates the
optional
local_rstn
signal.
app_rstn
which resets the Application
Layer logic is derived from
npor
. This reset controller is used for
Gen1 ES devices and Gen 1 and Gen2 production devices.
Soft Reset Controller
Either
pin_perstn
from the input pin of the FPGA or
npor
which is
derived from
pin_perstn
or
local_rstn
can reset the Hard IP for
PCI Express IP Core. Application Layer logic generates the optional
local_rstn
signal.
app_rstn
which resets the Application Layer
logic is derived from
npor
. This reset controller is used for Gen2 ES
devices and Gen3 ES and production devices.
