Chapter 8: Register Descriptions 8–23
Correspondence between Configuration Space Registers and the PCIe Spec 2.1
December 2013 Altera Corporation Cyclone V Hard IP for PCI Express
User Guide
0x050:0x05C MSI Capability Structure MSI and MSI-X Capability Structures
0x068:0x070 MSI Capability Structure MSI and MSI-X Capability Structures
0x070:0x074 Reserved
0x078:0x07C Power Management Capability Structure PCI Power Management Capability Structure
0x080:0x0B8 PCI Express Capability Structure PCI Express Capability Structure
0x080:0x0B8 PCI Express Capability Structure PCI Express Capability Structure
0x0B8:0x0FC Reserved
0x094:0x0FF Root Port
0x100:0x16C Virtual Channel Capability Structure (Reserved) Virtual Channel Capability
0x170:0x17C Reserved
0x180:0x1FC Virtual channel arbitration table (Reserved) VC Arbitration Table
0x200:0x23C Port VC0 arbitration table (Reserved) Port Arbitration Table
0x240:0x27C Port VC1 arbitration table (Reserved) Port Arbitration Table
0x280:0x2BC Port VC2 arbitration table (Reserved) Port Arbitration Table
0x2C0:0x2FC Port VC3 arbitration table (Reserved) Port Arbitration Table
0x300:0x33C Port VC4 arbitration table (Reserved) Port Arbitration Table
0x340:0x37C Port VC5 arbitration table (Reserved) Port Arbitration Table
0x380:0x3BC Port VC6 arbitration table (Reserved) Port Arbitration Table
0x3C0:0x3FC Port VC7 arbitration table (Reserved) Port Arbitration Table
0x400:0x7FC Reserved PCIe spec corresponding section name
0x800:0x834 Advanced Error Reporting AER (optional) Advanced Error Reporting Capability
0x838:0xFFF Reserved
Table 6-2. PCI Type 0 Configuration Space Header (Endpoints), Rev2.1
0x000 Device ID Vendor ID Type 0 Configuration Space Header
0x004 Status Command Type 0 Configuration Space Header
0x008 Class Code Revision ID Type 0 Configuration Space Header
0x00C
BIST Header Type Master Latency Time Cache Line
Size
Type 0 Configuration Space Header
0x010 Base Address 0 Base Address Registers (Offset 10h - 24h)
0x014 Base Address 1 Base Address Registers (Offset 10h - 24h)
0x018 Base Address 2 Base Address Registers (Offset 10h - 24h)
0x01C Base Address 3 Base Address Registers (Offset 10h - 24h)
0x020 Base Address 4 Base Address Registers (Offset 10h - 24h)
0x024 Base Address 5 Base Address Registers (Offset 10h - 24h)
0x028 Reserved Type 0 Configuration Space Header
0x02C Subsystem Device ID Subsystem Vendor ID Type 0 Configuration Space Header
0x030 Expansion ROM base address Type 0 Configuration Space Header
0x034 Reserved Capabilities PTR Type 0 Configuration Space Header
0x038 Reserved Type 0 Configuration Space Header
0x03C Max_Lat Min_Gnt Interrupt Pin Interrupt Line Type 0 Configuration Space Header
Table 8–39. Correspondence Configuration Space Registers and PCIe Base Specification Rev. 2.1 (Part 2 of 4)
Byte Address Hard IP Configuration Space Register Corresponding Section in PCIe Specification
