8–20 Chapter 8: Register Descriptions
PCI Express Avalon-MM Bridge Control Register Access Content
Cyclone V Hard IP for PCI Express December 2013 Altera Corporation
User Guide
Table 8–33 describes the
Interrupt Status
register for Root Ports. Refer to Table 8–35
for the definition of the
Interrupt Status
register for Endpoints.
Table 8–34 describes fields of the Avalon
Interrupt Enable
register for Root Ports.
Refer to Table 8–36 for the definition of this register for Endpoints.
PCI Express to Avalon-MM Interrupt Status and Enable Registers for
Endpoints
The registers in this section contain status of various signals in the PCI Express
Avalon-MM bridge logic and allow Avalon interrupts to be asserted when enabled. A
processor local to the interconnect fabric that processes the Avalon-MM interrupts can
access these registers.
1 These registers must not be accessed by the PCI Express Avalon-MM bridge master
ports; however, there is nothing in the hardware that prevents PCI Express
Avalon-MM bridge master port from accessing these registers.
Table 8–33. Avalon-MM Interrupt Status Registers for Root Ports 0x3060
Bits Name Access Mode Description
[31:5] Reserved — —
[4]
RPRX_CPL_RECEIVED
RW1C
Set to 1’b1 when the Root Port has received a
Completion TLP for an outstanding Non-Posted request
from the TLP Direct channel.
[3]
INTD_RECEIVED
RW1C The Root Port has received INTD from the Endpoint.
[2]
INTC_RECEIVED
RW1C The Root Port has received INTC from the Endpoint.
[1]
INTB_RECEIVED
RW1C The Root Port has received INTB from the Endpoint.
[0]
INTA_RECEIVED
RW1C The Root Port has received INTA from the Endpoint.
Table 8–34. INT-X Interrupt Enable Register for Root Ports 0x3070
Bit Name Access Mode Description
[31:5] Reserved — —
[4]
RPRX_CPL_RECEIVED
RW
When set to 1’b1, enables the assertion of
CraIrq_o
when the Root Port Interrupt Status register
RPRX_CPL_RECEIVED
bit indicates it has received a
Completion for a Non-Posted request from the TLP
Direct channel.
[3]
INTD_RECEIVED_ENA
RW
When set to 1’b1, enables the assertion of
CraIrq_o
when the Root Port Interrupt Status register
INTD_RECEIVED
bit indicates it has received INTD.
[2]
INTC_RECEIVED_ENA
RW
When set to 1’b1, enables the assertion of
CraIrq_o
when the Root Port Interrupt Status register
INTC_RECEIVED
bit indicates it has received INTC.
[1]
INTB_RECEIVED_ENA
RW
When set to 1’b1, enables the assertion of
CraIrq_o
when the Root Port Interrupt Status register
INTB_RECEIVED
bit indicates it has received INTB.
[0]
INTA_RECEIVED_ENA
RW
When set to 1’b1, enables the assertion of
CraIrq_o
when the Root Port Interrupt Status register
INTA_RECEIVED
bit indicates it has received INTA.
