8–12 Chapter 8: Register Descriptions
PCI Express Avalon-MM Bridge Control Register Access Content
Cyclone V Hard IP for PCI Express December 2013 Altera Corporation
User Guide
Avalon-MM to PCI Express Interrupt Registers
The registers in this section contain status of various signals in the PCI Express
Avalon-MM bridge logic and allow PCI Express interrupts to be asserted when
enabled. Only Root Complexes should access these registers; however, hardware does
not prevent other Avalon-MM masters from accessing them.
Table 8–25 shows the status of all conditions that can cause a PCI Express interrupt to
be asserted.
A PCI Express interrupt can be asserted for any of the conditions registered in the
Avalon-MM to
PCI Express
Interrupt Status
register by setting the corresponding
bits in the Avalon-MM-to-PCI Express
Interrupt Enable
register (Table 8–26). Either
MSI or legacy interrupts can be generated as explained in the section “Enabling MSI
or Legacy Interrupts” on page 11–7.
0x3A00-0x3A1F Avalon-MM-to-PCI Express Mailbox Registers 0x3A00–0x3A1F
0x3B00-0x3B1F PCI Express-to-Avalon-MM Mailbox Registers 0x3B00–0x3B1F
Table 8–24. PCI Express Avalon-MM Bridge Register Map (Part 2 of 2)
Address Range Register
Table 8–25. Avalon-MM to PCI Express Interrupt Status Register 0x0040
Bit Name Access Description
31:24 Reserved — —
23
A2P_MAILBOX_INT7
RW1C 1 when the A2P_MAILBOX7 is written to
22
A2P_MAILBOX_INT6
RW1C 1 when the A2P_MAILBOX6 is written to
21
A2P_MAILBOX_INT5
RW1C 1 when the A2P_MAILBOX5 is written to
20
A2P_MAILBOX_INT4
RW1C 1 when the A2P_MAILBOX4 is written to
19
A2P_MAILBOX_INT3
RW1C 1 when the A2P_MAILBOX3 is written to
18
A2P_MAILBOX_INT2
RW1C 1 when the A2P_MAILBOX2 is written to
17
A2P_MAILBOX_INT1
RW1C 1 when the A2P_MAILBOX1 is written to
16
A2P_MAILBOX_INT0
RW1C 1 when the A2P_MAILBOX0 is written to
[15:0] AVL_IRQ_ASSERTED[15:0] RO
Current value of the Avalon-MM interrupt (IRQ) input
ports to the Avalon-MM RX master port:
■ 0 – Avalon-MM IRQ is not being signaled.
■ 1 – Avalon-MM IRQ is being signaled.
A Qsys-generated IP Compiler for PCI Express has as
many as 16 distinct IRQ input ports. Each
AVL_IRQ_ASSERTED[] bit reflects the value on the
corresponding IRQ input port.
