Chapter 8: Register Descriptions 8–3
Configuration Space Register Content
December 2013 Altera Corporation Cyclone V Hard IP for PCI Express
User Guide
Table 8–4 describes the MSI Capability structure.
Table 8–5 describes the MSI-X Capability structure.
0x024
Prefetchable Memory Limit Prefetchable Memory Base
0x028
Prefetchable Base Upper 32 Bits
0x02C
Prefetchable Limit Upper 32 Bits
0x030
I/O Limit Upper 16 Bits I/O Base Upper 16 Bits
0x034 Reserved
Capabilities
Pointer
0x038 Expansion ROM Base Address
0x03C
Bridge Control Interrupt Pin Interrupt Line
Note to Table 8–3:
(1) Refer to Table 8–39 on page 8–22 for a comprehensive list of correspondences between the Configuration Space registers and the PCI Express
Base Specification 2.1.
Table 8–3. PCI Type 1 Configuration Space Header (Root Ports) (Part 2 of 2)
Byte Offset 31:24 23:16 15:8 7:0
Table 8–4. MSI Capability Structure, Rev2.1 Spec: MSI Capability Structures
Byte Offsets
(1)
31:24 23:16 15:8 7:0
0x050
Message Control
Configuration MSI Control Register Field
Descriptions
Next Cap Ptr Capability ID
0x054
Message Address
0x058
Message Upper Address
0x05C
Reserved Message Data
Note to Table 8–4:
(1) Specifies the byte offset within Cyclone V Hard IP for PCI Express IP core’s address space.
(2) Refer to Table 8–39 on page 8–22 for a comprehensive list of correspondences between the Configuration Space registers and the PCI Express
Base Specification 2.1.
Table 8–5. MSI-X Capability Structure, Rev2.1 Spec: MSI-X Capability Structures
Byte Offset 31:24 23:16 15:8 7:3 2:0
0x068
Message Control Next Cap Ptr Capability ID
0x06C
MSI-X Table Offset
MSI-X Table Offset BIR
0x070
PBA Offset
Pending Bit Array (PBA) Offset
Note to Table 8–5:
(1) Refer to Table 8–39 on page 8–22 for a comprehensive list of correspondences between the Configuration Space registers and the PCI Express
Base Specification 2.1.
