7–54 Chapter 7: IP Core Interfaces
Physical Layer Interface Signals
Cyclone V Hard IP for PCI Express December 2013 Altera Corporation
User Guide
ltssmstate0[4:0]
LTSSM state: The LTSSM state machine encoding defines the following
states:
■ 00000: detect.quiet
■ 00001: detect.active
■ 00010: polling.active
■ 00011: polling.compliance
■ 00100: polling.configuration
■ 00101: polling.speed
■ 00110: config.linkwidthstart
■ 00111: config.linkaccept
■ 01000: config.lanenumaccept
■ 01001: config.lanenumwait
■ 01010: config.complete
■ 01011: config.idle
■ 01100: recovery.rcvlock
■ 01101: recovery.rcvconfig
■ 01110: recovery.idle
■ 01111: L0
■ 10000: disable
■ 10001: loopback.entry
■ 10010: loopback.active
■ 10011: loopback.exit
■ 10100: hot.reset
■ 10101: LOs
■ 11001: L2.transmit.wake
■ 11010: speed.recovery
O
sim_pipe_rate[1:0]
O
Specifies the lane rate. The 2-bit encodings have the following
meanings:
■ 2’b00: Gen1 rate (2.5 Gbps)
■ 2’b01: Gen2 rate (5.0 Gbps)
■ 2’b1X: Reserved.
sim_pipe_pclk_in
I
This clock is used for PIPE simulation only, and is derived from the
refclk
. It is the PIPE interface clock used for PIPE mode simulation.
txswing0
O
Specifies the following TX voltage swing levels. A value of 0 specifies full
swing. A value of 1 specifies half swing.
Table 7–25. PIPE Interface Signals (Part 3 of 4)
Signal I/O Description
