Chapter 7: IP Core Interfaces 7–45
Avalon-MM Hard IP for PCI Express
December 2013 Altera Corporation Cyclone V Hard IP for PCI Express
User Guide
f Variations with Avalon-MM interface implement the Avalon-MM protocol described
in the Avalon Interface Specifications. Refer to this specification for information about
the Avalon-MM protocol, including timing diagrams.
32-Bit Non-Bursting Avalon-MM Control Register Access (CRA) Slave
Signals
The optional CRA port for the full-featured IP core allows upstream PCI Express
devices and external Avalon-MM masters to access internal control and status
registers. Table 7–20 describes the CRA slave signals.
Clock vv“Clock Signals” on page 7–24
Reset and Status vv “Reset Signals” on page 7–25
Physical and Test
Transceiver Control vv“Transceiver Reconfiguration” on page 7–48
Serial vv“Serial Interface Signals” on page 7–48
Pipe vv“PIPE Interface Signals” on page 7–52
Test vv“Test Signals” on page 7–55
Table 7–19. Signal Groups in the Avalon-MM Cyclone V Hard IP for PCI Express Variants (Part 2 of 2)
Signal Group
Full
Featured
Completer
Only Single
DWord
Description
Table 7–20. Avalon-MM CRA Slave Interface Signals
Signal Name I/O Type Description
CraIrq_o
O Irq Interrupt request. A port request for an Avalon-MM interrupt.
CraReadData_o[31:0]
O Readdata Read data lines.
CraWaitRequest_o
O Waitrequest Wait request to hold off more requests.
CraAddress_i[11:0]
I Address
An address space of 16,384 bytes is allocated for the control registers.
Avalon-MM slave addresses provide address resolution down to the
width of the slave data bus. Because all addresses are byte addresses,
this address logically goes down to bit 2. Bits 1 and 0 are 0.
CraByteEnable_i[3:0]
I Byteenable Byte enable.
CraChipSelect_i
I Chipselect Chip select signal to this slave.
CraRead
I Read Read enable.
CraWrite_i
I Write Write request.
CraWriteData_i[31:0]
I Writedata Write data.
