f For a description of the completion rules, the completion header format, and
completion status field values, refer to Section 2.2.9 of the PCI Express Base
Specification, Rev. 2.1.
Transaction Layer Configuration Space Signals
Table 7–10 describes the Transaction Layer Configuration Space signals.
cpl_err[6:0]
(continued)
■ cpl_err[6] : Log header. If header logging is required, this bit must be set in
every cycle in which any of
cpl_err[2] , cpl_err[3] , cpl_err[4] , or
cpl_err[5] is asserted. The Application Layer presents the header to the
Hard IP by writing the following values to the following 4 registers using LMI
before asserting
cpl_err[6] :
■ lmi_addr: 12'h81C, lmi_din : err_desc_func0[127:96]
■ lmi_addr: 12'h820, lmi_din : err_desc_func0[95:64]
■ lmi_addr: 12'h824, lmi_din : err_desc_func0[63:32]
■ lmi_addr: 12'h828, lmi_din : err_desc_func0[31:0]
Refer to the “LMI Signals” on page 7–39 for more information about LMI
signalling.
Due to clock-domain synchronization circuitry,
cpl_err is limited to at most 1
assertion every 8
pld_clk cycles. Whenever cpl_err is asserted,
cpl_err_func[2:0] should be updated in the same cycle.
cpl_err_func[2:0] I
Specifies which function is requesting the
cpl_err . Must be asserted when
cpl_err asserts. Due to clock-domain synchronization circuitry, cpl_err is
limited to at most 1 assertion every 8
pld_clk cycles. Whenever cpl_err is
asserted,
cpl_err_func[2:0] should be updated in the same cycle.
cpl_pending[7:0] I
Completion pending. The Application Layer must assert this signal when a
master block is waiting for completion, for example, when a transaction is
pending. This is a level sensitive input. A bit is provided for each function, where
bit 0 corresponds to function 0, and so on.
Table 7–9. Completion Signals for the Avalon-ST Interface (Part 2 of 2)
Signal I/O Description
Table 7–10. Configuration Space Signals (Hard IP Implementation) (Part 1 of 2)
Signal Dir Description
tl_cfg_add[6:0] 0
Address of the register that has been updated. This signal is an index indicating which
Configuration Space register information is being driven onto
tl_cfg_ctl. The indexing
is defined inTable 7–12 on page 7–35.The index increments every 8
coreclkout_hip
cycles. The index consists of the following 2 pars:
■ [6:4] - indicates the function number whose information is being presented on
tl_cfg_ctl
■ [3:0] - the tl_cfg_ctl multiplexor index
tl_cfg_ctl[31:0] 0
The
tl_cfg_ctl signal is multiplexed and contains the contents of the Configuration
Space registers. The information presented on this bus depends on the
tl_cfg_add index
according toTable 7–12 on page 7–35.
tl_cfg_ctl_wr 0
Write signal. This signal toggles when
tl_cfg_ctl has been updated (every 8 core_clk
cycles). The toggle edge marks where the
tl_cfg_ctl data changes. You can use this
edge as a reference to determine when the data is safe to sample.
