Chapter 7: IP Core Interfaces 7–29
Cyclone V Hard IP for PCI Express
December 2013 Altera Corporation Cyclone V Hard IP for PCI Express
User Guide
Interrupts for Root Ports
Table 7–9 describes the signals available to a Root Port to handle interrupts.
Completion Side Band Signals
Table 7–9 describes the signals that comprise the completion side band signals for the
Avalon-ST interface. The Cyclone V Hard IP for PCI Express provides a completion
error interface that the Application Layer can use to report errors, such as
programming model errors. When the Application Layer detects an error, it can assert
the appropriate
cpl_err
bit to indicate what kind of error to log. The Hard IP sets the
appropriate status bits for the errors in the Configuration Space, and automatically
sends error messages in accordance with the PCI Express Base Specification. Note that
the Application Layer is responsible for sending the completion with the appropriate
completion status value for non-posted requests. Refer to Chapter 14, Error Handling
for information on errors that are automatically detected and handled by the Hard IP.
app_msi_func[2:0]
I
Indicates which function is asserting an interrupt with 0 corresponding to function 0, 1
corresponding to function 1, and so on.
app_int_sts_vec[7:0]
I
Level active interrupt signal. Bit 0 corresponds to function 0, and so on. Drives the INTx
line for that function. The core maps this status to INT A/B/C/D according to each
function’s
Interrupt_Pin
register. The core internally wire-ORs the INT requests from
all sources, and generates INT MSGs on the rising/falling edges of the wire-ORed result.
The core logs the
tl_app_int_sts_vec
status in each functions’ PCI Status register.
Table 7–8. Interrupt Signals for Endpoints (Part 2 of 2)
Signal I/O Description
