7–18 Chapter 7: IP Core Interfaces
Cyclone V Hard IP for PCI Express
Cyclone V Hard IP for PCI Express December 2013 Altera Corporation
User Guide
tx_cred_fchipcons
6O
component
specific
Asserted for 1 cycle each time the Hard IP consumes a
credit. The 6 bits of this vector correspond to the following
6 types of credit types:
■ [5]: posted headers
■ [4]: posted data
■ [3]: non-posted header
■ [2]: non-posted data
■ [1]: completion header
■ [0]: completion data
During a single cycle, the Hard IP can consume either a
single header credit or both a header and a data credit. The
Application Layer must keep track of credits consumed by
the Application Layer logic.
tx_cred_fc_infinite
6O
component
specific
When asserted, indicates that the corresponding credit
type has infinite credits available and does not need to
calculate credit limits. The 6 bits of this vector correspond
to the following 6 types of credit types:
■ [5]: posted headers
■ [4]: posted data
■ [3]: non-posted header
■ [2]: non-posted data
■ [1]: completion header
■ [0]: completion data
tx_cred_hdrfccp
8O
component
specific
Header credit limit for transmission of completions. Each
credit is 20 bytes.
tx_cred_hdrfcnp
8O
component
specific
Header limit for transmission of non-posted requests. Each
credit is 20 bytes.
tx_cred_hdrfcp
8O
component
specific
Header credit limit for transmission of posted writes. Each
credit is 20 bytes.
ko_cpl_spc_header
8O
component
specific
ko_cpl_spc_header
is a static signal that indicates the
total number of completion headers that can be stored in
the RX buffer. The Application Layer can use this signal to
build circuitry to prevent RX buffer overflow for completion
headers. Endpoints must advertise infinite space for
completion headers; however, RX buffer space is finite.
Table 7–4. 64- or 128-Bit Avalon-ST TX Datapath (Part 3 of 4)
Signal Width Dir
Avalon-ST
Type
Description
