Chapter 1: Datasheet 1–3
Features
December 2013 Altera Corporation Cyclone V Hard IP for PCI Express
User Guide
f The purpose of the Cyclone V Hard IP for PCI Express User Guide is to explain how to
use the Cyclone V Hard IP for PCI Express and not to explain the PCI Express
protocol. Although there is inevitable overlap between these two purposes, this
document should be used in conjunction with an understanding of the following PCI
Express specifications: PHY Interface for the PCI Express Architecture PCI Express 2.0 and
PCI Express Base Specification 2.1.
Transaction Layer Packet Types (TLP) (3)
■ Memory Read Request
■ Memory Read Request-Locked
■ Memory Write Request
■ I/O Read Request
■ I/O Write Request
■ Configuration Read Request
(Root Port)
■ Configuration Write Request
(Root Port)
■ Message Request
■ Message Request with Data
Payload
■ Completion without Data
■ Completion with data
■ Completion for Locked Read
without Data
■ Memory Read Request
■ Memory Write Request
■ Configuration Read Request
(Root Port)
■ Configuration Write Request
(Root Port)
■ Message Request
■ Message Request with Data
Payload
■ Completion without Data
■ Completion with Data
■ Memory Read Request (single
dword)
■ Memory Write Request (single
dword)
Maximum payload size 128–512 bytes 128–256 bytes
Number of tags supported for non-posted
requests
32 or 64 8
62.5 MHz clock Supported Supported
Multi-function
Supports up to 8 functions Supports single function only
Polarity inversion of PIPE interface signals Supported Supported
ECRC forwarding on RX and TX Supported Not supported
Expansion ROM Supported Not supported
Number of MSI requests 16 1, 2, 4, 8, or 16
MSI-X Supported Supported
Multiple MSI, MSI-X, and INTx Not Supported Supported
Legacy interrupts Supported Supported
Notes to Table 1–2:
(1) Not recommended for new designs.
(2) ×2 is supported by down training from ×4 or ×8 lanes.
(3) Refer to Appendix A, Transaction Layer Packet (TLP) Header Formats for the layout of TLP headers.
Table 1–1. Differences in Features Available Using the Avalon-MM and Avalon-ST Interfaces (Part 2 of 2)
Feature Avalon-ST Interface Avalon-MM Interface
