7–8 Chapter 7: IP Core Interfaces
Cyclone V Hard IP for PCI Express
Cyclone V Hard IP for PCI Express December 2013 Altera Corporation
User Guide
rx_st_bar
8O
component
specific
The decoded BAR bits for the TLP. Valid for
MRd
,
MWr
,
IOWR
, and
IORD
TLPs; ignored for the completion or message TLPs. Valid
during the cycle in which
rx_st_sop
is asserted. Figure 7–8
illustrates the timing of this signal for 64-bit data. Figure 7–11
illustrates the timing of this signal for 128-bit data.
The following encodings are defined for Endpoints:
■ Bit 0: BAR 0
■ Bit 1: BAR 1
■ Bit 2: Bar 2
■ Bit 3: Bar 3
■ Bit 4: Bar 4
■ Bit 5: Bar 5
■ Bit 6: Expansion ROM
■ Bit 7: Reserved
The following encodings are defined for Root Ports:
■ Bit 0: BAR 0
■ Bit 1: BAR 1
■ Bit 2: Primary Bus number
■ Bit 3: Secondary Bus number
■ Bit 4: Secondary Bus number to Subordinate Bus number
window
■ Bit 5: I/O window
■ Bit 6: Non-Prefetchable window
■ Bit 7: Prefetchable window
Table 7–3. 64- or 128-Bit Avalon-ST RX Datapath (Part 3 of 4)
Signal Width Dir
Avalon-ST
Type
Description
