Chapter 7: IP Core Interfaces 7–7
Cyclone V Hard IP for PCI Express
December 2013 Altera Corporation Cyclone V Hard IP for PCI Express
User Guide
rx_st_valid
1O
valid
Clocks
rx_st_data
into the Application Layer. Deasserts
within 2 clocks of
rx_st_ready
deassertion and reasserts
within 2 clocks of
rx_st_ready
assertion if more data is
available to send.
rx_st_valid
can be deasserted between the
rx_st_sop
and
rx_st_eop
even if
rx_st_ready
is asserted.
rx_st_err
1O
error
Indicates that there is an uncorrectable ECC error in the internal
RX buffer. Active when ECC is enabled. ECC is automatically
enabled by the Quartus II assembler. ECC corrects single-bit
errors and detects double-bit errors on a per byte basis.
When an uncorrectable ECC error is detected,
rx_st_err
is
asserted for at least 1 cycle while
rx_st_valid
is asserted. If
the error occurs before the end of a TLP payload, the packet
may be terminated early with an
rx_st_eop
and with
rx_st_valid
deasserted on the cycle after the eop.
Altera recommends resetting the Cyclone V Hard IP for PCI
Express IP core when an uncorrectable (double-bit) ECC error
is detected.
Component Specific Signals
rx_st_mask
1I
component
specific
The Application Layer asserts this signal to tell the Hard IP to
stop sending non-posted requests. This signal can be asserted
at any time. This signal does not affect non-posted requests
that have already been transferred from the Transaction Layer
to the application interface. The total number of non-posted
requests that can be transferred to the application after
rx_st_mask
is asserted not more than 14 for 64-bit mode.,
and is not more than 26 for 128-bit mode.
Table 7–3. 64- or 128-Bit Avalon-ST RX Datapath (Part 2 of 4)
Signal Width Dir
Avalon-ST
Type
Description
