(modified if necessary) In addition, one more identical display and mounting hardware
shall be provided, mounted in a similar fashion, between the current displays on the
east wall. The three displays shall be set so that everyone in the room, including the
Commission staff, can see one of the displays.
All three new displays shall be connected to separate Enova outputs via HDMI.
Displays shall be connected for control via RS232 and control programming added to
the AMX system. Recommended display model: Samsung ME55B.
The staff desk, to the west of the room, shall include Enova input points, by way of
Enova wall plates installed on the desks, to replace the current analog connection
points.
The Sympodium device, relocated from the Council Chambers shall have its output
(VGA) connected to the Enova system at the Staff Desk.
An Owner furnished Granicus webcasting unit (video/audio input plus LAN) shall be
integrated and programmed into the TV production system by the AV Contractor.
Cameras
Four new Panasonic AW-HE50SN remote pan/tilt SDI/HD-SDI cameras are to be
installed in the Room A ceiling. A new Panasonic AW-RP50N camera controller shall
be installed in the Control Room. Coaxial HD-SDI cables and CAT6 UTP cables shall
be installed from each camera to the Control room. AC power sockets shall be
provided for each camera in the ceiling. The cameras shall be installed “base up”. See
AV plan for provisional location of cameras, but AV contractor shall verify final location
with the Owner, which may require a site visit to set up a camera with the controller
and a video monitor locally in the room to evaluate each proposed position’s view of
the room. Each camera shall transmit SDI/HD-SDI signal via coaxial cable to the
Control room. Each camera shall be connected for serial control from the new camera
controller via UTP cable.
Control
A new network switch shall be installed in the AV rack – with new Gigabit cable
connections to both Council Chamber rack room and the Control room. AV Contractor
shall verify the distance for these new cable runs and provide either copper or fiber
optic connections as is appropriate to gigabit networking standards. The City of
Beverly Hills uses Extreme Networks switches as their IT standard, so AV contractor
shall follow suit for this project. All new AV devices shall connect to this new AV
network. The AV network shall also be transporting QLAN traffic from the new Qsys
DSP system.
The control shall be AMX Netlinx. The entire system programming shall be created
from new to take into account the new systems and their functionality. All current touch
screens shall be removed.
