The Public Podium shall be refitted with Enova input panels. A new Smart Podium
ID500 display device shall be provided (the existing Sympodium is to be moved to
Room A) and its DVI output shall be connected to the Enova.
Control
A new network switch shall be installed in the AV rack – with new Gigabit cable
connections to both Room A rack room and the Control room. AV Contractor shall
verify the distance for these new cable runs and provide either copper or fiber optic
connections as is appropriate to gigabit networking standards. The City of Beverly Hills
uses Extreme Networks switches as their IT standard, so AV contractor shall follow
suit for this project. All new AV devices shall connect to this new AV network. The AV
network shall also be transporting QLAN traffic from the new Qsys DSP system.
A Wireless Access Point shall be added in the room, connected to the AV network
switch. WAP shall be an Extreme Networks model.
The control shall be AMX Netlinx. The entire system programming shall be created
from new to take into account the new systems and their functionality. All current touch
screens shall be removed and replaced.
The existing Netlinx NI-3100 in the small AV rack shall be relocated to the large rack
and become the central controller for the Chamber. A new 10” AMX surface mount
touch screen shall be provided in the AV rack as the control interface for the system.
The GUI for this screen shall allow for video routing, audio routing, and access to DSP
functions such as microphone settings. The intercom feature shall also be enabled
allowing for voice communication to the new AMX screen to be installed in the Control
room. A second new desktop 10” AMX touch screen shall be located, with an RJ45
Ethernet connection panel, on the Staff Desk. The GUI for this screen shall be a
simplified version of the rack screen, allowing for day to day operation as required by
the staff in the Chambers. A simplified approach to the GUI should be taken, with the
use of preset buttons etc.
The Public Podium raise and lower controls shall remain connected to the AMX
system. The wall mounted AMX button panel (lighting control) shall remain connected
to the AMX system.
It is envisioned that all system programming will be performed via laptop PC.
Programming software shells shall be provided to the City of Beverly Hills by the AV
Contractor so that the Owner can setup their own laptop for maintenance use and/or
login to the systems from a remote PC in the control room. The AV Contractor shall
provide their own laptop/PC for system programming/commissioning/training
purposes.
