D ESIGN C ONSULTING
Electrosonic Systems, Inc. Page 2 of 11
Design Consulting DEC100167 www.electrosonic.com
3320 N. San Fernando Blvd. Beverly Hills City Hall Tel: +1-818-333-3600
Burbank, CA 91504, USA Television Production AVC Systems Upgrade Fax: +1-818-566-4923
Control Room to both the Council Chambers and Room A AV rack rooms. Most of the
new cable run requirements are Gigabit CAT6A cables, and coaxial HD-SDI cables.
The four new cameras and LCD screens in Room A shall require new power drops, AV
contractor shall liaise with City Hall on the best way to achieve this, in terms of suitable
existing breaker panel locations that can be used.
All new UTP & network cable runs shall be shielded CAT6A
Recommended CAT6A type: Belden 10GX52F (or plenum equivalent if
required)
Recommended Coaxial type: Belden 1505A (or plenum equivalent if required)
All network switches shall be Extreme Networks X450e variants to comply with City of
Beverly Hills standards, and shall be certified for use with QSC Qsys systems.
All new system software programming (AMX, QSYS etc), shall be created from new.
All programming files shall become the property of the City of Beverly Hills upon
project handover. All system passwords shall be provided to the City of Beverly Hills,
with no exceptions.
Please read & review the document attachments:
AVC Design Intent Drawings – Oct 15, 2012 – from Electrosonic
AVC – General Specifications
AVC Equipment List – Major Components
AVC Cut Sheets
AMX – Cabling for Success with DXLink
QSC – QLAN White Paper
QSC - QLAN Networking Overview
Available As Built Drawings (PDF):
o Hoffman Final AV Drawings BEVERLY_HILLS__AS_BUILD – August 03,
2006
o TV Pro Gear Drawings – Aug 15, 2008
o Pro Sound Audio System Drawings - Aug 02, 2001
Council Chambers
The primary Council Chambers room, located on the second floor, has an existing
AVC system in place. This, in simple terms, consists of:
Audio system – switched microphones on the council desks, DSP system,
amplifiers, speakers.
Video system – analog composite and RGBHV switching and distribution with
tie-lines to the control room, flat screen LCD monitors, large LCD displays.
Control system – AMX
Wireless microphone and Assisted Listening systems
The intent is to replace the analog system components with a new digital system. A
new networkable DSP system shall replace the Media Matrix, and a digital video
