Specifications
Table Of Contents
SCALE
ISSUE DATE
AV DRAWING SHEET INDEX
REVISION DATE
SHEET TITLESHEET NUMBER
NONE
OCTOBER 15, 2012
AV SHEET INDEX & GENERAL NOTES
AV0.03 AV SYMBOL LEGEND
AV0.01
AV0.02
NONE
OCTOBER 15, 2012
NONE
OCTOBER 15, 2012
AV ABBREVIATIONS
AV GENERAL NOTES FOR OWNER, ARCHITECT & GENERAL CONTRACTORS
EQUIPMENT PLANS, TECHNICAL DRAWINGS AND DOCUMENT NOTES:
1. THESE AV EQUIPMENT PLANS, TECHNICAL DRAWINGS AND DOCUMENTS ARE TO ILLUSTRATE GENERAL
AV SYSTEMS INTEGRATION CONCEPTS ONLY. THE EXACT LOCATIONS AND INSTALLATION METHODS OF ALL
ASSOCIATED DEVICES SHALL BE COORDINATED WITH THE AV SYSTEMS DESIGNER, GENERAL
CONTRACTOR, CONSULTING ELECTRICAL ENGINEER, ELECTRICAL CONTRACTOR AND THE APPROPRIATE
AUTHORITIES HAVING JURISDICTION. THE LOCATIONS CONTAINED HEREIN ARE BASED SOLELY ON
PRELIMINARY DESIGNS AND ALL FINAL LOCATIONS ARE TO BE VERIFIED WITH THE OWNER'S
REPRESENTATIVE ON SITE PRIOR TO INSTALLATION.
2. THE AV SYSTEMS DESIGNER HAS TAKEN GREAT CARE TO PREVENT CONFLICTS IN THE REQUIREMENTS
THAT ARE DETAILED HERE IN THESE TECHNICAL DRAWINGS AND DOCUMENTS. HOWEVER, IF A CONFLICT IS
IDENTIFIED, THE APPROPRIATE CONTRACTOR SHALL IMMEDIATELY NOTIFY THE AV SYSTEMS DESIGNER IN
WRITING AS TO THE NATURE OF THE CONFLICT NOTED SO CLARIFICATIONS CAN BE PROVIDED AND A
RESOLUTION IMPLEMENTED.
3. NO CHANGE OR MODIFICATION OF DESIGN SHALL OCCUR WITHOUT WRITTEN APPROVAL OF AV SYSTEMS
DESIGNER.
4. THE INFORMATION AND DESIGNS EXPRESSED HEREIN ARE PROPRIETARY AND CONFIDENTIAL AND MAY
NOT BE USED OR COPIED WITHOUT THE EXPRESS WRITTEN CONSENT OF ELECTROSONIC INC., 3320
NORTH SAN FERNANDO BLVD., BURBANK, CA 91504.
INSTALLATION NOTES:
1. THE DESIGNATED GENERAL AND ELECTRICAL CONTRACTORS (SPECIFIED HEREIN AS "THE
CONTRACTORS") SHALL PROVIDE, LOCATE AND INSTALL ALL AV SYSTEMS CONDUIT, CABLE, CABLE PULLS,
CABLE TRAYS, CABLE TERMINATORS, BUSHINGS, J-BOXES, FLOOR BOXES, ENCLOSURES, PLATES AND
PANELS, POWER CIRCUITS, POWER CABLE, POWER CONNECTIONS, ETC. DESCRIBED IN THESE
DOCUMENTS. THE CONTRACTORS SHALL DETERMINE SCOPE OF WORK WITHIN THEIR DISCIPLINES. THE
DESIGNATED AV CONTRACTOR SHALL PROVIDE ALL OTHER CUSTOM AV SYSTEMS CONNECTOR PANELS
AND DEVICES, AS NOTED: "BY AV CONTRACTOR".
2. THE CONTRACTORS ARE RESPONSIBLE FOR ADHERING TO ALL NATIONAL AND LOCAL ELECTRICAL, FIRE
AND BUILDING CODE REQUIREMENTS.
3. ALL AV SYSTEMS EQUIPMENT SHALL BE PROVIDED WITH STANDARD MANUFACTURER'S COLOR AND
FINISH UNLESS OTHERWISE SPECIFIED BY THE OWNER AND APPROVED BY AV SYSTEMS DESIGNER PRIOR
TO BID AND INSTALLATION.
4. ALL AV SYSTEMS DEVICE MOUNTING ATTACHMENTS SHALL BE DESIGNED TO PROVIDE EASE OF
MAINTENANCE AND SERVICE. STAINLESS STEEL SAFETY CABLES SHALL BE INSTALLED ON ALL SUSPENDED
EQUIPMENT.
5. THE CONTRACTORS SHALL SUPPORT ALL AV SYSTEMS LOUDSPEAKER ENCLOSURE ASSEMBLIES FROM
STRUCTURE RATHER THAN FROM THE FACILITY FINISHED CEILING, PROVIDING SAFETY CABLES TO
STRUCTURAL STEEL AND SEISMICALLY BRACE EQUIPMENT AS REQUIRED.
6. THE CONTRACTORS SHALL PROVIDE A MINIMUM OF 36" (915mm) UNOBSTRUCTED ACCESS FROM THE
FRONT AND REAR OF ALL FREE STANDING AV SYSTEMS RACK ASSEMBLIES, UNLESS OTHERWISE NOTED.
7. THE CONTRACTORS SHALL PROVIDE A MINIMUM OF 36" (915mm) UNOBSTRUCTED ACCESS ON ONE SIDE
OF ALL FREE STANDING AV SYSTEMS RACK ASSEMBLIES, UNLESS OTHERWISE NOTED.
8. THE CONTRACTORS SHALL PROVIDE A MINIMUM OF 36" (915mm) UNOBSTRUCTED ACCESS FROM THE
FRONT OF ALL WALLS MOUNTED AV SYSTEMS RACK ASSEMBLIES, UNLESS OTHERWISE NOTED.
9. THE CONTRACTORS SHALL PROVIDE A MINIMUM OF 12" (305 mm) UNOBSTRUCTED ACCESS FROM THE
TOP OF ALL AV SYSTEMS RACK ASSEMBLIES TO THE BOTTOM OF ALL OVERHEAD CABLE TRAY
ASSEMBLIES AND 12" (305mm) FROM THE TOP OF ALL CABLE TRAY ASSEMBLIES TO THE FACILITY FINISHED
CEILING, UNLESS OTHERWISE NOTED.
10. THE CONTRACTORS SHALL INSTALL AV SYSTEMS LOUDSPEAKER BACK BOXES THAT ARE PROVIDED BY
THE AV SYSTEMS CONTRACTOR. THE AV SYSTEMS CONTRACTOR SHALL INSTALL AND TERMINATE (LOW
VOLTAGE ONLY) AT ALL AV SYSTEMS LOUDSPEAKERS, VIDEO MONITORS, PROJECTORS, PROJECTION
SCREENS, CUSTOM PANELS AND AV SYSTEMS CONTROL DEVICES.
11. THE CONTRACTORS SHALL PROVIDE ALL CABLE RUNS TERMINATING AT SPEAKER BREAKOUT BOX
LOCATIONS. THESE RUNS SHALL BE ENCLOSED IN FLEX CONDUIT REACHING TO THE SPEAKER
TERMINATION POINTS AND CONTAIN A MINIMUM 36" (915mm) PIGTAIL AT LOUDSPEAKER FOR CONNECTION
BY THE AV CONTRACTOR.
12. THE CONTRACTORS SHALL PROVIDE A SERVICE LOOP NO LESS THAN 10'-0" (3.1M) AT ALL AV SYSTEMS
RACK LOCATIONS AND NO LESS THAN 36" (915mm) AT ALL AV SYSTEMS PULL AND BREAKOUT BOXES,
UNLESS OTHERWISE NOTED.
13. ALL AV SYSTEMS JUNCTION BOXES AND OTHER WIRING DEVICES ARE SUGGESTED MINIMUM SIZES
AND CAN BE INCREASED IN SIZE WITH SUITABLE TIMELY NOTIFICATION TO AND AGREEMENT FROM THE AV
SYSTEM DESIGNER AND AV CONTRACTOR. AV SYSTEMS DESIGNER AND/OR AV CONTRACTOR ASSUMES NO
RESPONSIBILITY FOR SIZING OF CONDUIT. THE SIZE VALUES IN THIS DOCUMENT ARE ESTIMATES ONLY
AND MUST BE IN ACCORDANCE WITH THE MANUFACTURERS RECOMMENDATION, LOCAL AND NATIONAL
CODES FOR CONDUIT FILL AND PULLING TENSION.
14. ALL AV SYSTEMS MOUNTING HEIGHT IS TO BOTTOM OF DEVICE, UNLESS OTHERWISE NOTED.
INSTALLATION NOTES (CONTINUED):
15. ALL AV SYSTEMS MINIMUM STANDARD RECEPTACLE HEIGHT IS 15 INCHES (380mm) ABOVE
FINISHED FLOOR, UNLESS OTHERWISE NOTED.
16. ALL AV SYSTEMS MINIMUM STANDARD SWITCH HEIGHT IS 48 INCHES (1220mm) ABOVE
FINISHED FLOOR UNLESS OTHERWISE NOTED.
17. ALL AV SYSTEMS BOXES AND CONDUIT IN NEW WALLS AND CEILINGS SHALL BE FLUSH
MOUNTED OR CONCEALED FROM GUESTS VIEW, UNLESS OTHERWISE NOTED.
18. ALL AV SYSTEMS DEVICE PLATE FINISHES AND TYPE ARE TO BE VERIFIED IN WRITING WITH
THE ARCHITECT AND/OR SCENIC DESIGNER WITH AV SYSTEMS CONTRACTOR.
CABLING AND CONDUIT NOTES:
1. ALL AV SYSTEMS WIRING SHALL BE IN CONDUIT UNLESS OTHERWISE NOTED. LOW LEVEL
AUDIO CABLES, CONTROL CABLES, VIDEO CABLES AND HIGH LEVEL SPEAKER CABLE SHALL BE
ROUTED IN SEPARATE GALVANIZED STEEL CONDUITS WITH A MINIMUM 6 INCHES (155mm)
SPACING. VERIFY IN WRITING THE COMBINING OF HOME RUNS WITH THE AV CONTRACTOR PRIOR
TO BID AND INSTALLATION.
2. ALL AV SYSTEMS CABLE RUNS, INCLUDING COAX CABLE, MUST BE CONTINUOUS FROM
SOURCE TO DESTINATION WITHOUT SPLICES. NO EXCEPTIONS.
3. THE CONTRACTORS SHALL PROVIDE PLENUM RATED CABLES IF REQUIRED BY AUTHORITY
HAVING JURISDICTION.
4. ALL AV SYSTEMS CONDUIT SHALL NOT EXCEED 100 FEET (30.1M) OR A TOTAL OF 270 DEGREES
IN BENDS BETWEEN PULL BOXES OR AS RECOMMENDED BY CABLE MANUFACTURER.
5. THE CONTRACTORS SHALL PERMANENTLY AND UNIQUELY LABEL ALL CABLE, CONDUIT AND
BOXES FOR EASE OF IDENTIFICATION.
6. THE CONTRACTORS SHALL PULL A METERED AND LABELED PULL STRING IN ALL CONDUITS,
REGARDLESS OF FILL.
7. ALL CABLING SHALL BE TESTED FOR CONTINUITY PRIOR TO CONNECTION TO AV EQUIPMENT
BY THE CONTRACTORS. ALL CATEGORY 5 (CAT5) AND CATEGORY 5E (CAT5E) CABLES SHALL BE
TESTED TO BISCI STANDARDS AND A TEST REPORT PROVIDED PRIOR TO CONNECTION OF ALL AV
SYSTEMS OR SHOW EQUIPMENT AFTER TERMINATION INTO THE DESIGNATED JACKS.
POWER CONNECTION NOTES:
1. THE CONTRACTORS SHALL USE #12 AWG MINIMUM STRANDED COPPER CONDUCTORS FOR ALL
AV POWER CIRCUITS, UNLESS OTHERWISE NOTED. ALL AV CIRCUITS WILL BE FED FROM THE AV
ISOLATED GROUND POWER PANEL. THE ISOLATED GROUND POWER PANEL SHALL BE FED FROM
A DEDICATED SHIELDED ISOLATION TRANSFORMER.
2. ALL AV SYSTEMS CIRCUITS REQUIRE INDEPENDENT NEUTRAL, GROUND AND ISOLATED
GROUND CONDUCTORS OF EQUAL CURRENT CARRYING CAPACITY PER CIRCUIT, UNLESS
OTHERWISE NOTED.
3. ALL AV SYSTEMS INTER-RACK AND INTERNAL DEDICATED ELECTRONIC ENCLOSURE WIRING TO
BE PROVIDED BY THE INSTALLING AV CONTRACTOR, UNLESS OTHERWISE NOTED.
ELECTRONIC EQUIPMENT ROOM (EER) REQUIREMENTS:
1. THE CONTRACTORS TO INSURE THAT ALL ELECTRONIC EQUIPMENT ROOMS BE CLEAN AND
DUST FREE PRIOR TO INSTALLATION OF ANY AV ELECTRONIC EQUIPMENT.
2. THE CONTRACTORS TO PROVIDE SEPARATE DEDICATED HVAC UNIT CAPABLE OF CONTINUOUS
24 HOURS OF UNINTERRUPTED OPERATION PER DAY FOR THE ELECTRONIC EQUIPMENT ROOM.
THIS UNIT SHALL BE OPERATIONAL FOR MINIMUM OF 48 HOURS AND THE FILTERS REPLACED
PRIOR TO INSTALLATION OF AV SYSTEMS RACKS.
3. ADDITIONAL POWER SPECIFICATIONS AND HVAC REQUIREMENTS TO BE DETAILED IN THE
CONSTRUCTION DOCUMENTS. THE ELECTRONIC EQUIPMENT ROOM SHALL BE MAINTAINED FROM
4. THE CONTRACTORS SHALL SEAL ALL CONCRETE SURFACES, WALLS, FIRE PROOFING, ETC.
AND/OR PROVIDE VINYL FLOOR, PAINTED WALLS AND DROP ACOUSTICAL CEILING IN THE
ELECTRONIC EQUIPMENT ROOM TO PREVENT DUST IN THE EQUIPMENT AREA THAT WILL AFFECT
THE AV SYSTEMS SHOW EQUIPMENT.
LIFE-SAFETY SYSTEMS:
1. ALL LIFE-SAFETY SYSTEM RELATED DESIGN, ENGINEERING, PROCUREMENT, AND
INSTALLATION IS BY GENERAL CONTRACTOR.
2. FACILITY FIRE ALARM SYSTEM SHALL PROVIDE A SET OF DRY NORMALLY CLOSED CONTACTS
TO INHIBIT AV, LIGHTING AND SHOW SYSTEM DURING A FIRE CONDITION WHEN REQUIRED BY
THE AUTHORITY HAVING JURISDICTION.
AV7.01 OVERALL: AV SINGLE LINE BLOCK DIAGRAM
NONE
OCTOBER 15, 2012
AV7.02 OVERALL: AV SINGLE LINE BLOCK DIAGRAM
NONE
OCTOBER 15, 2012
AV7.03
OVERALL: AV SINGLE LINE BLOCK DIAGRAM
NONE
OCTOBER 15, 2012
AV7.04 OVERALL: AV SINGLE LINE BLOCK DIAGRAM
NONE
OCTOBER 15, 2012
AV7.05
OVERALL: AV SINGLE LINE BLOCK DIAGRAM
NONE
OCTOBER 15, 2012
AV7.06 OVERALL: AV SINGLE LINE BLOCK DIAGRAM
NONE
OCTOBER 15, 2012
AV7.07
OVERALL: AV SINGLE LINE BLOCK DIAGRAM
NONE
OCTOBER 15, 2012
AV7.08 OVERALL: AV SINGLE LINE BLOCK DIAGRAM
NONE
OCTOBER 15, 2012
AV7.09 OVERALL: AV SINGLE LINE BLOCK DIAGRAM
NONE
OCTOBER 15, 2012
AV7.10 OVERALL: AV SINGLE LINE BLOCK DIAGRAM
NONE
OCTOBER 15, 2012
AV7.11 OVERALL: AV SINGLE LINE BLOCK DIAGRAM
NONE
OCTOBER 15, 2012
AV7.12 OVERALL: AV SINGLE LINE BLOCK DIAGRAM
NONE
OCTOBER 15, 2012
AV7.13 OVERALL: AV SINGLE LINE BLOCK DIAGRAM
NONE
OCTOBER 15, 2012
AV7.14 OVERALL: AV SINGLE LINE BLOCK DIAGRAM
NONE
OCTOBER 15, 2012
AV5.01
MAIN CHAMBER AV RACK ROOM: AV EQUIPMENT RACK ELEVATION
1-1/2" = 1'-0"
OCTOBER 15, 2012
AV5.02
ROOM 'A' AV RACK ROOM: AV EQUIPMENT RACK ELEVATION
1-1/2" = 1'-0"
OCTOBER 15, 2012
AV1.01 MAIN CHAMBER: AV PLANS
1/4" = 1'-0"
OCTOBER 15, 2012
AV1.02 ROOM 'A': AV PLANS
1/4" = 1'-0"
OCTOBER 15, 2012
AV7.15 OVERALL: AV SINGLE LINE BLOCK DIAGRAM
NONE
OCTOBER 15, 2012
AV7.16
OVERALL: AV SINGLE LINE BLOCK DIAGRAM
NONE
OCTOBER 15, 2012
THE DATA IN THIS DOCUMENT INCORPORATES
PROPRIETARY RIGHTS OF ELECTROSONIC INC. ANY
PARTY ACCEPTING THIS DOCUMENT DOES SO IN
CONFIDENCE & AGREES THAT IT SHALL NOT BE
DUPLICATED IN WHOLE, OR IN PART NOR DISCLOSED
TO OTHERS, WITHOUT THE WRITTEN CONSENT OF
ELECTROSONIC INC.
2012 ELECTROSONIC INC.
ISSUE
REVISIONS
DESIGN INTENT
OCT 15, 2012
DEC100167
c
S. COE
EDC
AV0.01
AV SHEET INDEX
& GENERAL NOTES
OCTOBER 05, 2012
NONE
