Overview
2
Solecis AVS-SL-PR-0401-0601 Presentation Switcher
AVS-SL-PR-0401-0601 Specifications (Cont.)
Sync Input
Type: Analog or TTL
Max Level: 5V p-p
Impedance: 75 ohm
Video Input
Number 6
Connectors Phono/RCA/Captive-wire 4Pin Din S-Video
Type YC or Composite
Level: Analog
Max Input: 1V P-P
Impedance: 75 Ohm
Bandwidth 50MHz -3dB
Return Loss: -30dB@1MHz, -22dB@5MHz
Differential Phase Error 0.05%
Differential Gain Error 0.03%
Crosstalk -60dB@1MHz
Audio Input
Number 10
Connectors Phono/RCA
Type Stereo Unbalanced Analog
Max Level 2V P-P
Impedance 47K
Audio Response 20-50 KHz
RGB Output
Number: 2
Connector: HD-15
Level: Analog
Gain: Unity
Impedance: 75 ohm
Sync Level: TTL
Sync Impedance: 75 ohm
Video Output
Number 2
Type YC or Composite
Connectors Phono/RCA/Captive-wire 4Pin Din S-Video
Level: Analog
Gain: Unity
Audio Output
Number 2
Connector Captive-wire
Type Stereo Unbalanced and Balanced Analog
Attenuation: 0 to -78dB
Impedance 600 Ohm
Control
Type: RS232 Send and Receive, Front Panel
Connector: Captive-Wire
Protocol: Baud Rate-9600, Data Bits-8, No Parity, Stop Bits-1
Address: 00 – FF software programmable
Input: RS232
Serial Output: Programmable Protocol
Type: Power On/Off, RGB Input, Composite Input and YC Input
Audio Breakaway: Available through RS232 command
