Operation (Front Panel Pushbuttons)
11
Solecis AVS-SL-PR-0401-0601 Presentation Switcher
RS232 Control
The unit may be controlled using an RS232 outputting system as follows.
Connection
Protocol
Baud Rate = 9600
Data Bits = 8
Parity = None
Stop Bit = 1
The default address of the 2011 is 0.
Controller 2011
GND GND
TX RX
RX TX (if feedback information required)
All commands are hexadecimal. Refer to the SET Commands section on page 13
and the GET Commands section on page 15 for details.
