Operation (Front Panel Pushbuttons)
10
Solecis AVS-SL-PR-0401-0601 Presentation Switcher
Display Device Serial Output
This can be used for direct control of any device with RS232 control (i.e: a projector).
The AVS-SL-PR-0401-0601 can be programmed to transmit Power On/Off as well as RGB, Composite
and S-Video mode commands to a display device using the Solecis Device Configuration Software
application (downloadable from www.amx.com).
Dip switches 1-6 must be set to match the incoming source type on their
corresponding inputs.
The projector or display device should be switched to match the Source type output.
The commands are transmitted from the Display Serial terminal.
Input mode only
When the AVS-SL-PR-0401-0601 is powered up a mode command will be sent to a display on the first
press of any Input select button. The command will either be RGB, Composite or S-Video depending on
the button pressed. This will ensure a display device is set to the correct mode to display the input
selected. Each time a different source type is selected then a mode command will be sent to the display
device. For this function to work the Display must be ON.
Power On/Off mode
When the AVS-SL-PR-0401-0601 is powered up, a Power On command is sent to a display on the first
press of any input button.
The button will flash for a programmed set time and the unit will disable. This allows a
projector to warm up.
At the end of the warm up period an RGB, Composite or S-Video command is sent to the
display, the AVS-SL-PR-0401-0601 enables and the system is ready for use.
To turn the controlled display (projector) off, press and hold the “Blank ON/OFF” pushbutton
(on the front panel) for 5 seconds.
Programming Cable Connections
Display Connections
If the Power ON/OFF function is to be enabled, set a warm up/cool down time via the
Power On Timer and Power Off Timer settings, and click on Set / Enable - see
Controlling External Display Devices.
PC Serial Port (D9) 2011
Pin2 TX
Pin3 RX
Pin5 GND
Display device 2011
RX Display serial o/p
GND GND
