2.6.4 Loading Media in Cutter Mode (Option)
1. Install the label. (Please refer to chapter 2.6.1)
2. Lead the media through the cutter paper opening.
3. Adjust the label guide to fit the width of the label.
4. Close the print head mechanism
making sure the latches are engaged
properly.
5. Use the DiagTool to set the printer setting to cutter mode. (Please refer to chapter 4)
Press the FEED button to test.
Note: Please calibrate the gap/black mark sensor when changing media.
Cutter paper
openin
g
