All in One Printer User Manual

20
3. Lead the media through the print head module and under the paper
sensor guide. (Figure 8)
4. Return the outside media guide, close the bracket, and hook the head
latch. (Figure 9)
9
Head
Latch
Outside Media Guide
Bracket
8
Print Head
Module
Paper Sensor
Guide Module
