PC215E
6.6.5.4 Free Differential Counter Pair - TCfreeDiffCounters
Frees the counter/timers associated with a differential pair, as setup by function
TCsetDifferentialCounters. Call this function when finished with the differential counter.
i = TCfreeDiffCounters (h, hD)
where
h Integer. Board handle as issued by function
registerBoard.
hD Integer. Differential counter handle as issued by
the TCsetDiffCounters function.
Returns Integer:
OK
or ERRHANDLE
ERRCHAN
Prior Calls registerBoard
TCsetDiffCounters
See Also TCgetDiffCount
TCgetRatio
