Page
65
PC215E
6.6.3.7 Write Data to an Integer Buffer - writeIntegerBuf
Writes a single integer data item to an integer data buffer.
i = writeIntegerBuf (b, item, data)
where b
Integer: buffer handle
item
Long: index of item in buffer
data
Integer: data value
Returns Integer:
OK
or ERRBUFFER
ERRRANGE
ERRDATA
Prior Calls registerBoard
allocateIntegerBuf
See Also
6.6.3.8 Write Data to a Long Integer Buffer - writeLongBuf
Writes a single long integer data item to a long data buffer.
i = writeLongBuf (b, item, data)
where b
Integer: buffer handle
item
Long: index of item in buffer
data
Long: data value
Returns Integer:
OK
or ERRBUFFER
ERRRANGE
ERRDATA
Prior Calls registerBoard
allocateLongBuf
See Also
