Instruction manual
Table Of Contents
- INTRODUCTION
- GETTING STARTED
- MAKING THE CONNECTIONS
- USING THE PC215E
- STRUCTURE AND ASSIGNMENTS OF THE REGISTERS
- Register Assignments
- Register Groups
- The Register Details
- Programmable Peripheral Interface PPI-X Data Register Port A
- Programmable Peripheral Interface PPI-X Data Register Port B
- Programmable Peripheral Interface PPI-X Data Register Port C
- Programmable Peripheral Interface PPI-X Command Register
- Programmable Peripheral Interface PPI-Y Data Register Port A
- Programmable Peripheral Interface PPI-Y Data Register Port B
- Programmable Peripheral Interface PPI-Y Data Register Port C
- Programmable Peripheral Interface PPI-Y Command Register
- Z1 Counter 0 Data Register
- Z1 Counter 1 Data Register
- Z1 Counter 2 Data Register
- Counter/Timer Z1 Control Register
- Z1 Counter/Timer Status Register
- Z2 Counter 0 Data Register
- Z2 Counter 1 Data Register
- Z2 Counter 2 Data Register
- Counter/Timer Z2 Control Register
- Z2 Counter/Timer Status Register
- Group Z Clock Connection Register
- Group Z Gate Connection Register
- Interrupt Source Selection Register
- Interrupt Status Register
- PROGRAMMING THE PC215E
- Copyright
- Files installed from the Distribution Diskette
- Windows DLL and Examples
- DOS 'C' Library and Examples
- Using the Dynamic Link Library
- Windows and DOS Library Functions
- Initialisation Functions
- Interrupt Control Functions
- Data Buffer Functions
- Timer/Counter Functions
- Differential Counter Functions
- Frequency Generation Functions
- Millisecond Stopwatch Functions
- Frequency Input and Output Functions
- Digitally- and Voltage-Controlled Oscillator Functions
- Digital Input/Output Functions
- Switch Scanner Matrix Functions
- Bi-Directional Data Bus Functions
- PC215E Library Error Codes
- PC215E Interface Guide For LABTECH NOTEBOOK
- Guide to User Programming
- Signal Centre
- CONTENTS
- DECLARATION OF CONFORMITY
PC215E Page 2
1.2.2 Product List
Product Number Product Type Brief Description
PC212E Counter/timer, Digital I/O board 12 counters, clock/gate source, 24 line digital I/O
PC214E Counter/timer, Digital I/O board 3 counters, 48 line digital I/O
PC215E Counter/timer, Digital I/O board 6 counters, clock/gate source, 48 line digital I/O
PC218E Counter/timer board 18 counters, clock/gate source
PC272E Digital I/O board 72 line digital I/O
EX233 Termination/distribution panel 78 Terminals, 3 x 37 way distribution connectors
EX213 Output panel 24 relay or high level logic source drivers
EX230 Input panel 24 isolated or non-isolated, high or low level inputs
EX221 Input/output panel 16 inputs, 8 outputs
90 966 349 78 way Screened Cable 1m I/O board to EX233 Termination/distribution panel
90 956 109 37 way Screened Cable 1m PC36AT or EX233 to I/O panel
91 945 753 37 way Screened Connector Kit
PC36AT 24 Line Digital I/O Board
908 919 50 37 way screw terminal assy
919 459 53 78 way Screened Connector Kit
1.3 Product Configurator
Figure 1 - Product Configurator Block Diagram - shows how the six digital I/O boards (including
the PC36AT) may be connected, using the supplied cables, to form a variety of systems. The
simplest usable system configuration comprises one board from the PC212E, PC214E,
PC215E, PC218E or PC272E range, a 78 way cable and an EX233. This system provides user
terminals to all I/O functions of the board. More complex, configurable systems include isolated
or common ground input and output at low or high level.
All five boards employ the concept of I/O Groups, where a group can be six 16 bit counter timers
with interconnects, or 24 lines of digital input/output. These groups are integrated as necessary
to provide the specified functionality.
A software configurable clock and gate source group provides five precise frequencies for
counter/timer input, and also allows for counter/timer inter-connection.
The user I/O connector map recognises this grouping and allows any combination of expansion
panels to be directly added to any of the boards, with each panel mapped onto a counter/timer
group or digital I/O group.
