PC215E Page 36
FUNCTION
The Z1 Counter 0 Data Register is used to write and read 8 bit data to the 82C54 Z1
counter/timer 0. The counter is normally configured for 16 bit operation and to ensure validity of
the data it is important to always write/read two bytes to the register, least significant byte first.
Please note that the 16-bit count values written to this register are not latched into the counting
element until the next clock pulse (assuming the gate input is high). Subsequent read
operations from this register will therefore not reflect the new count value until this clock pulse
has latched the data.
The counter can be configured to operate in several modes. Further details may be found by
reference to the device manufacturer's 82C54 data sheets in the appendices.
The input to counter 0 can be any of the five internal master clock frequencies (10 MHz, 1 MHz,
100 kHz, 10 kHz or 1 kHz), an external clock, the Z1 External Clock signal or the output of Z2
counter 2. This clock source selection is made by writing to the Group Z Clock Connection
Register described in Section 5.3.19.
The output of counter 0 is available on the user socket, SK1 pin 15, and also as a possible clock
source for counter 1. The inverted output of Z1 counter 0 is also available on SK1 pin 54.
The gate input to counter 0 can be selected as VCC (permanently enabled), GND (permanently
disabled), the inverted output of Z2 Counter 1, or an external gate signal on SK1 pin 73. This
gate selection is made by writing to the Group Z Gate Connection Register described in Section
5.3.20.
Further information on programming the 82C54 Programmable Counter/Timer is given in
chapters 4 and 6.
BIT ASSIGNMENTS
The bit layout of the Z1 counter 0 data register is shown below.
01234567
Second Byte
(Most Significant)
8
9
10
11
12
13
14
15
First Byte
(Least Significant)
0
1
2
3
4
5
6
7
Z1 16 BIT COUNTER 0 DATA BIT
