Page
15
PC215E
62 Pin Connector
Ground < B1 A1 < -I/O CHCK (
bracket end of board)
+ Reset < B2 A2 < > SD7
+5 Volts < B3 A3 < > SD6
+IRQ2/9* > B4 A4 < SD5
-5 Volts < B5 A5 < > SD4
+DRQ2 > B6 A6 < > SD3
-12 Volts < B7 A7 < > SD2
-0WS < > B8 A8 < > SD1 C
+12 Volts < B9 A9 < > SD0 O
Ground < B10 A10 < I/O CHRDY M
S -SMEMW < B11 A11 < > AEN P
O -SMEMR < B12 A12 < > SA19 O
L -IOW < > B13 A13 < > SA18 N
D -IOR < > B14 A14 < > SA17 E
E -DACK3 < > B15 A15 < > SA16 N
R +DRQ3 < > B16 A16 < > SA15 T
-DACK1 < > B17 A17 < > SA14
S +DRQ1 < > B18 A18 < > SA13 S
I -DACK0 < > B19 A19 < > SA12 I
D CLK < > B20 A20 < > SA11 D
E +IRQ7 < > B21 A21 < > SA10 E
+IRQ6 < > B22 A22 < > SA9
+IRQ5 < > B23 A23 < > SA8
+IRQ4 < > B24 A24 < > SA7
+IRQ3 < > B25 A25 < > SA6
-DACK2 < > B26 A26 < > SA5
+T/C < B27 A27 < > SA4
+BALE < B28 A28 < > SA3
+5 Volts < B29 A29 < > SA2
OSC < B30 A30 < > SA1
Ground < B31 A31 < > SA0
36 Pin Connector
–MEMCS16 > D1 C1 > SBHE
–I/OCS16 > D2 C2 < > LA23
+IRQ10 > D3 C2 < > LA22
+IRQ11 > D4 C4 < > LA21
+IRQ12 > D5 C5 < > LA20
+IRQ15 > D6 C6 < > LA19
+IRQ14 > D7 C7 < > LA18
–DAC0 < D8 C8 < > LA17
+DRQ0 > D9 C9 >–MEMR
–DACK5 < D10 C10 >–MEMW
+DRQ5 > D11 C11 <> SD08
–DACK6 < D12 C12 <> SD09
+DRQ6 > D13 C13 <> SD10
–DACK7 < D14 C14 <> SD11
+DRQ7 > D15 C15 <> SD12
+5 VoltS < D16 C16 <> SD13
–MASTER > D17 C17 <> SD14
Ground < D18 C18 <> SD15
Figure 6 - PC Backplane - ISA Bus Connections
