PC215E Page 110
6.9 Guide to User Programming
When developing an application specific program, it is advised that the supplied dynamic link
library functions are used for Windows applications and extracts are taken from the DOS
examples. However if there are good reasons for writing low level code then a study of the
source code supplied will be of assistance.
For programming at register level, reference should to be made to section 5 describing the
function and assignments of each I/O register in the PC215E.
6.10 Signal Centre
Signal Centre is a Signal Processing Applications Program available from Amplicon, with
support for the PC215E. Operates under Microsoft Windows.
