UZ130.
GENERAL INFORMATION EN Dear Customer, The Amica appliance is a combination of exceptional user-friendliness and excellent efficiency. Prior to dispatch, each unit was carefully checked for its safety and operating capabilities. Before starting the appliance, please read this operating manual carefully. Note! This freezer is intended for use at home only. The manufacturer reserves the right to introduce modifications, which do not affect the operation of the appliance.
TABLE OF CONTENTS Construction and equipment of the appliance...........................................................................3 Guidelines concerning the safety of use...................................................................................5 Installation.................................................................................................................................6 Operation and functions....................................................................................
CONSTRUCTION AND EQUIPMENT OF THE APPLIANCE Example 1 2 Items of equipment 1 Control panel 2 Drawer UZ130.
GUIDELINES CONCERNING THE SAFETY OF USE l The Manufacturer shall not be held liable for the damage arising from the failure to observe the principles contained in this manual. l Keep this manual for future reference, or to pass it over to the possible next user.
INSTALLATION AND OPERATING CONDITIONS OF THE APPLIANCE 5. Ensure that the product is level by adjusting the 4 adjustable legs (fig. 2). Installation before using the appliance for the first time 1. Take the product out of the package, remove the scotch tapes protecting the door and the equipment. The possibly remaining adhesive stains may be removed with a mild washing agent. 2. Do not throw away the polystyrene elements of the packaging.
INSTALLATION AND OPERATING CONDITIONS OF THE APPLIANCE It is prohibited to readjust or modify any parts of the unit. It is crucial not to damage the capillary tube visible in the compressor recess. The tube may not be bent, straightened and wound. If the capillary tube is damaged by the user the guarantee will be void (fig. 4). This appliance must be earthed The flexible cord (mains lead) fitted to this appliance has three cores for use with a 3-pin 13-amp plug.
OPERATION AND FUNCTIONS Control panel 1. Thermostat dial The thermostat automatically keeps the internal temperature at a constant level. The temperature is regulated by the thermostat dial, located on the freezer control panel. To change the temperature, turn the dial anti-clockwise from 1 (highest temperature) to 5 (coldest temperature). We recommend that you start with the appliance set to position 3. 2. Super freeze switch This freezer is equipped with a super freeze function.
OPERATION AND FUNCTIONS Storage of food in the freezer Observe the following recommendations to ensure the food remains fresh. Freezing food l Practically all the food products, except for vegetables consumed raw, such as lettuce can be frozen. l Only food products of the highest quality, divided into small portions for single use, should be frozen. l Products should be packed in materials that are odourless, resistant to air and moisture penetration, and not susceptible to fat.
OPERATION AND FUNCTIONS The time of storage of the frozen products depends on their quality when fresh, before freezing and on the storage temperature.
USING THE REFRIGERATOR EFFICIENTLY Understanding the stars Practical everyday tips l Do not place fridges or freezers next to radiators, heaters, stoves or in direct sunlight. l Make sure that air vents are not covered up and clean the dust off them once or twice a year. l Select the right temperature: 6 to 8°C in your refrigerator and -18°C in your freezer is sufficient. l When on holiday, turn up the temperature in your fridge. l Only open your fridge or freezer when necessary.
USING THE REFRIGERATOR EFFICIENTLY 12
DEFROSTING, WASHING AND MAINTENANCE Defrosting the freezer In order to defrost the freezer chamber, you must take the following steps: l It is recommended to combine defrosting the appliance with washing it. l Excessive accumulation of ice on the freezing areas impairs the appliance’s freezing capacity and increases the energy consumption. l Defrost the appliance at least once or twice a year. l If there is food in the freezer, set the knob to the max. position about 4 hours before the planned defrosting.
TROUBLE-SHOOTING Problems Possible causes Remedies The appliance does not work Electric circuit rupture - check whether the plug is properly inserted into the socket - check whether the power cable of the appliance is not damaged - check whether there is voltage in the socket, by plugging another appliance, e.g. a night lamp - check whether the appliance is switched on by setting the thermostat to a position above 0.
TROUBLE-SHOOTING Problems The appliance works continuously The appliance generates unusual noise Possible causes Remedies The compressor is switched on too rarely - check whether the ambient temperature is not lower than 16°C Door gasket inserted incorrectly - press the gasket in Incorrect setting of the adjustment knob - reset the knob to a lower position See. ”Temperature inside the appliance is not low enough for description of other possible causes See.
Environmental protection Ozone layer protection The refrigerants and foaming agents, which are 100% free of FCKW and FKW have been used for manufacturing our product. Therefore we help protecting the ozone layer and prevent the greenhouse effect increase. On the other hand, the innovative technology and environmentally friendly insulation help in reducing energy consumption.
SPECIFICATION TYPE Manufacturer Type of the appliance UZ130.3 AMICA WRONKI S.A.
SPECIFICATION Climate range means that your set temperature is maintained at ”normal” ambient temperature. Should the room temperture drop significantly below the defined scope, the appliance does not work so often and the undesirable temperature increase may occure dojść do niepożądanego wzrostu temperatury. A++/A+ (=low consumption) to G (=high consumption). 2) The energy consumption refers to the yearly consumption in kWh, indicated according to DIN EN 153.
Service Help Line For the UK: please call 0844 815 8880 For Ireland: please call 0818 46 46 46 IOLS-1057/1 (04.
