Operation
Setup Menu : Misc
3.10.3.6.14 Volt Meter Lock
This picklist value specifies whether use of the
VOLT METER
SHIFT-key command is locked or unlocked. The default value is
Unlocked.
3.10.3.6.15 Fine Adjust Lock
This picklist value specifies whether use of the
FINE ADJUST
SHIFT-key command is locked or unlocked. The default value is
Unlocked.
3.10.3.6.16 Coil Constant Lock
This picklist value specifies whether the Coil Constant value
(under the Load submenu) is locked or unlocked. The default value
is Unlocked.
3.10.3.6.17 Current Limit Lock
This picklist value specifies whether the Current Limit value
(under the Load submenu) is locked or unlocked. The default value
is Unlocked.
+50.00 A — Volt Meter Lock
+0.50 Vs Locked Unlocked
+50.00 A — Fine Adjust Lock
+0.50 Vs Locked Unlocked
+50.00 A — Coil Constant Lock
+0.50 Vs Locked Unlocked
+50.00 A — Current Limit Lock
+0.50 Vs Locked Unlocked
