Operation
Setup Menu : Misc
value (under the Misc submenu) and editing of the Ramp Time
Units value (under the Misc submenu). The default value is
Unlocked.
3.10.3.6.6 Power Supply Lock
This picklist value specifies whether the Select Supply picklist
value is locked or unlocked. If the Select Supply value is Custom...,
then setting Power Supply Lock to Locked also prevents the custom
power supply parameters (Min Output Voltage, Max Output
Voltage, Min Output Current, Max Output Current and V-V Mode
Input Range) from being edited. The default value is Unlocked.
3.10.3.6.7 Voltage Limit Lock
This picklist value specifies whether use of the
VOLTAGE LIMIT
SHIFT-key menu is locked or unlocked. The default value is
Unlocked.
3.10.3.6.8 Reset Quench Lock
This picklist value specifies whether use of the
RESET QUENCH
SHIFT-key command is locked or unlocked. The default value is
Unlocked.
3.10.3.6.9 Incr./Decr. Field Lock
This picklist value specifies whether use of the
INCR. FIELD and
DECR. FIELD SHIFT-key commands is locked or unlocked. The
default value is Unlocked.
+50.00 A — Power Supply Lock
+0.50 Vs Locked Unlocked
+50.00 A — Voltage Limit Lock
+0.50 Vs Locked Unlocked
+50.00 A — Reset Quench Lock
+0.50 Vs Locked Unlocked
+50.00 A — Incr./Decr. Field Lock
+0.50 Vs Locked Unlocked
