62 Rev. 5
Operation
Setup Menu : Misc
3.10.3.6.1 PSwitch Control Lock
This picklist value specifies whether use of the
PERSIST. SWITCH
CONTROL
key is locked or unlocked. The default value is
Unlocked.
3.10.3.6.2 Target Field Setpt Lock
This picklist value specifies whether use of the
TARGET FIELD
SETPOINT
key is locked or unlocked. The default value is
Unlocked.
3.10.3.6.3 Ramp / Pause Lock
This picklist value specifies whether use of the
RAMP / PAUSE key
is locked or unlocked. The default value is Unlocked.
3.10.3.6.4 Ramp To Zero Lock
This picklist value specifies whether use of the
RAMP TO ZERO
key is locked or unlocked. The default value is Unlocked.
3.10.3.6.5 Ramp Rate Settings Lock
This picklist value specifies whether ramp rate settings are locked
or unlocked. Ramp rate settings protected by this setting are: use of
the RAMP RATE SHIFT-key menu, editing of the Ramp Segments
+50.00 A — PSwitch Control Lock
+0.50 Vs Locked Unlocked
+50.00 A — Target Field Setpt Lock
+0.50 Vs Locked Unlocked
+50.00 A — Ramp / Pause Lock
+0.50 Vs Locked Unlocked
+50.00 A — Ramp To Zero Lock
+0.50 Vs Locked Unlocked
+50.00 A — Ramp Rate Settings Lock
+0.50 Vs Locked Unlocked
