44 Rev. 5
Operation
Setup Menu : Supply
If using a standard power supply supported by AMI, selecting a power
supply within the Select Supply picklist sets all the remaining parameters
in the supply submenu per Table 3-2 on page 45.
Note
The Supply submenu is unique in that it has only the Select Supply
picklist as a sublevel (unless Custom is chosen from the picklist of
Select Supply options). For this reason, picklist entry is active as
soon as the Supply submenu is selected; it is not necessary to first
press enter to make picklist entry active in the Select Supply picklist.
Also, pressing
ESC while within the Select Supply picklist not only
makes picklist entry inactive and sets the picklist selection back to
where it was when the Supply submenu was selected; it also exits the
Select Supply picklist.
3.10.1.1 Select Supply Picklist
The Select Supply picklist provides a set of picklist items that
contain presets for standard AMI power supplies. The left and right
keypad arrows are used to cycle through the list of selections. When
the item selector points at the desired power supply in the picklist,
ENTER is pressed to select that power supply; all power supply
parameters are set when the power supply model is selected.
Pressing
ESC while viewing the Select Supply picklist leaves the
power supply selection where it was when the Supply submenu was
selected, and exits the Select Supply picklist. The available Select
Supply picklist values and associated power supply parameters are
provided in Table 3-2 on page 45.
+0.00 A — Select Supply*
+0.50 Vs AMI 4Q06125PS
