Setup Submenu : Supply
user will be able to edit parameters under that submenu. See setup menu
structure in Figure 3-7 below.
3.10.1 Supply Submenu
The Model 430 Programmer has been configured as part of the 4Q1010PS-
430 Power Supply System. It should not be necessary to change this
selection. However, the Supply submenu information that follows in
Section 3.10.1 is provided in the event that the power supply system/model
must be changed.
The Supply submenu provides for the specification of the power supply
parameters. If you wish to set the limits of operation for a connected
magnet, refer to the Current Limit
1
and the Voltage Limit
2
configuration
sections.
1. Refer to section 3.10.2.4 on page 52.
2. Refer to section 3.7.2 on page 36.
LOAD
STABILITY
SETTING
COIL
CONSTANT
CURRENT
LIMIT
MAGNET CURRENT
RATING
CALCULATE MAGNET
INDUCTANCE
PSWITCH
INSTALLED?
PSw CURRENT
DETECT
PSWITCH
CURRENT
PSWITCH
HEATED TIME
PSWITCH
COOLED TIME
PSWITCH
P/S RAMP RATE
PSWITCH
COOLING GAIN
ENABLE QUENCH
DETECT?
ENERGY ABSORBER
PRESENT?
EXTERNAL RAMP-
DOWN DISABLED?
MISC
DISPLAY
BRIGHTNESS
RAMP
SEGMENTS
RAMP RATE
TIME UNITS
FIELD
UNITS
QUENCH
RATE
SETTINGS
PROTECTION
SETTINGS
PASSWORD
SETUP MENU
SUPPLY
SELECT SUPPLY
CUSTOM
MIN OUTPUT
VOLTAGE
MAX OUTPUT
VOLTAGE
MIN OUTPUT
CURRENT
MAX OUTPUT
CURRENT
V-V MODE
INPUT RANGE
NET SETTINGS
ADDRESS
ASSIGNMENT
SYSTEM
NAME
IP
ADDRESS
SUBNET
MASK
GATEWAY
ADDRESS
NET SETUP
IP ADDRESS
ASSIGNMENT
SYSTEM IP
ADDRESS
SUBNET
MASK
GATEWAY IP
ADDRESS
AMI 12100PS
AMI 12200PS
AMI 4Q05100PS
AMI 4Q06125PS
AMI 4Q06250PS
AMI 4Q12125PS
AMI 10100PS
OTHERS…
0 to -5
0 to +5
0 to +10
-5 to +5
-10 to +10
NET SETUPNET SETTINGS NET SETUPMISC NET SETTINGS NET SETUPLOAD MISC NET SETTINGS NET SETUPSUPPLY LOAD MISC NET SETTINGS NET SETUP
SELECT SUPPLYSELECT SUPPLY
CUSTOM
SELECT SUPPLY
CUSTOM
SELECT SUPPLY
Figure 3-7. Setup Menu Structure
