Introduction
Power Supply Front Panel Layout
1.5 System Specifications @ 25°C
Magnet Current Control
Range: −10 to +10 A
Programming Accuracy: 4 mA
Stability: 2 mA after 20 min. at desired current
Minimum Ramp Rate: 10 μA/min
Maximum Ramp Rate: 1 A/sec
Output Voltage
Range: −10 to +10 Vdc
Measurement Resolution: 10 mV
Load Inductance
Range: 0.5 to 100 H
Primary Power Requirements
Range: 100 - 115 or 200 - 230 Vac ±10%
50 / 60 Hz, 1200 VA
Physical
Dimensions
a
:
a. H = height; W = width; D = depth
12.5” H x 21” W x 24.5” D
(318 mm H x 533 mm W x 622 mm D)
Approximate Weight: 85 lbm (40 kg)
Terminal Torque Limit: 48 lbf-in (5.4 N-m)
Environmental Limits
Ambient Temperature: 0 °C to 40 °C (32 °F to 104 °F)
Relative Humidity: 0 to 95%; non-condensing
