Introduction
Model 430 Front Panel
1.2 Model 430 Front Panel Layout
1 Power Indicator LED 8 Fine Adjust Knob
2 280 x 16 Dot Graphic VF Display 9 Persistent Switch Heater Control Key
3 Shift Indicator LED 10 Target Field Setpoint Key
4 Shift Key 11 Ramp/Pause Switch
5 4 Row x 3 Column Keypad 12 Menu Navigation and Data Entry Keys
6 Power Switch 13 Ramp to Zero Key
7 Magnet Status Indicator LEDs
Table 1-1. Model 430 Front Panel Description
