162 Rev. 5
Appendix
Power Supply Details
A.11.1 Model 4Q1010PS Electrical Specifications
1
Table A-11 lists Model 4Q1010PS electrical specifications.
1. Details for the stand-alone units are provided for reference only.
Many of the basic power supply parameters will not apply in the
closed loop current feedback system application with the AMI Model
430 Programmer controlling current in the outer loop.
Table A-11. Model 4Q1010PS Electrical Specifications
Specification Rating / Description Condition/Comment
INPUT CHARACTERISTICS
Voltage
95 - 113 Vac, 50-60 Hz
Selectable
105 - 125 Vac, 50-60 Hz
190 - 226 Vac, 50-60 Hz
210 - 250 Vac, 50-60 Hz
Current 5.5 Aac Line voltage 176 Vac, 60 Hz
Common mode leakage current 5 mA p-p ac 115 Vac, 60 Hz
OUTPUT CHARACTERISTICS
Output Range
E
O Max
-20 to +20 Vdc
AMI limits voltage to ±10 Vdc
I
O Max
-10 A to +10 Adc
Closed Loop Gain Voltage Channel 2.0
Source/sink
adjustment range
Voltage -20 to +20 Vdc
AMI limits voltage to +/-10 Vdc
Current -10 A to +10 Adc
Rise/Fall Time (resis-
tive load)
Voltage 20 μS / 20 μS Maximum - measured from 10
to 90%, 0 to ±100% of rating
Current 60 μS / 60 μS
Frequency band-
width (resistive load)
Voltage 18 kHz
Minimum
Current 6 kHz
