Appendix
Model 430 Specifications
Programmable Limits: 0.0 to 125 mA dc
Accuracy: 0.2 mA
Temperature Coefficient: 0.01 mA per °C
Maximum Compliance: 14 V
Resolution: 0.03 mA
Rampdown and Quench Inputs
Open Circuit Voltage: 5 Vdc ± 5%
Input Resistance: 10 k-ohm ± 1%
Quench Dry Contact Output
Maximum Switching Voltage: 60 Vdc
Maximum Switching VA: 10 VA
Maximum Switching Current: 500 mA, unless limited by VA rating
Galvanic Isolation: 125 Vdc
Power Requirements
Primary: 100-115 Vac or 200-230 Vac ±10%
50 / 60 Hz, 100 VA max., 30 W max.
Real-time Clock Backup Battery: 3 V CR2032 Lithium coin cell
Physical
Dimensions: 89 mm H x 483 mm W x 191 mm D
(3.5" H x 19" W x 10.75" D)
Weight: 8.5 lbm (3.9 kg)
Terminal Torque Limit: 48 lbf-in (5.4 N-m).
Environmental
Ambient Temperature: Operating: 0°C to 50°C (32°F to 122°F)
Non-operating: −20°C to 70°C (−4°F to 158°F)
Relative Humidity: 0 to 95%; non-condensing
Terminal Torque Limit: 48 lbf-in (5.4 N-m)
Standards
EMI/EMC Standards: EN 61000-4-2 EN 61000-4-3
EN 61000-4-4 EN 61000-4-5
EN 61000-4-6 EN 61000-4-8
EN 61000-4-11 EN 61000-3-2
EN 61000-3-3 EN 55011
Safety Standard: EN61010-1
Installation Category: Pollution Degree 2, Overvoltage Category II
as defined by IEC664
