Rev. 5 111
Remote Interface Reference
SETUP Configuration Commands and Queries
• SUPPly:TYPE?
Returns the index according to the table below for the selected power
supply type according to the table below. This value can be configured only
via front panel operation of the SUPPLY setup menu.
• SUPPly:VOLTage:MINimum?
Returns the minimum power supply compliance setting in volts. This value
can be configured only via front panel operation using the Supply submenu
and is set automatically when a preset supply type is selected.
• SUPPly:VOLTage:MAXimum?
Returns the maximum power supply compliance in volts. This value can be
configured only via front panel operation using the Supply submenu and is
set automatically when a preset supply type is selected.
Table 4-3. Return Values and Meanings for SUPPly:TYPE? Query
Return
Value Meaning
0 AMI 12100PS
1 AMI 12200PS
2 AMI 4Q05100PS
3 AMI 4Q06125PS
4 AMI 4Q06250PS
5 AMI 4Q12125PS
6 AMI 10100PS
7 AMI 10200PS
8 HP 6260B
9 Kepco BOP 20-5M
10 Kepco BOP 20-10M
11 Xantrex XFR 7.5-140
12 Custom
13 AMI Model 05100PS-430-601
14 AMI Model 05200PS-430-601
15 AMI Model 05300PS-430-601
16 AMI Model 05400PS-430-601
17 AMI Model 05500PS-430-601
