4 Remote Interface Reference
The Model 430 Programmer provides both RS-232 and Ethernet interfaces
as standard features. The serial and Ethernet interfaces may operated
simultaneously. Separate output buffers are also provided for the serial
and Ethernet return data. However, for optimal performance and
simplicity of programming, AMI normally recommends limiting operation
to one interface. An exception to this recommendation would be using the
serial port as a debugging aid during programming of the Ethernet port (or
vice-versa), which can prove to be a useful resource.
4.1 SCPI Command Summary
The following manual conventions are used for SCPI (Standard
Commands for Programmable Instruments) syntax for the remote
interface commands:
• Braces { } enclose valid parameter choices.
• A vertical bar | separates multiple choices for each parameter.
• Triangle brackets < > indicate that you must supply a value.
• Parentheses ( ) within < > indicate alternative units are available.
For example, the command PSwitch {0|1} indicates that the command
PSwitch has two parameter options: 0 or 1. Refer to the detailed
description of each command for information regarding specific parameter
choices and their meanings. Capitalized portions of the commands indicate
acceptable abbreviations. Default settings are shown in bold.
(see page 108 for more information)
*IDN?
*RST
*TST?
<
Ctrl-C>
SYSTem:LOCal
SYSTem:REMote
SYSTem:TIME?
SYSTem:TIME:SET <date(mm/dd/yyyy) time(hh:mm:ss)>
SYSTem:ERRor?
System-Related Commands
